Mobile dvr for vehicle for car
All kind of Cameras(it's not included into the Mdvr,but we can customize manufacturing it with mdvr for you)
Product Specification: AHD mdvr
| Item | parameter | |
| Operating System | Linux | |
| Language | English/chinese/customized | |
| Video Compression | H.264 Compression | |
| OSD | overlays information such as date time and vehicle ID | |
| GUI | Graphical user interface | setup system parameters with the remote control |
| Video Record System | video input | 4CH 960P/720P AHD input,aviation connector, 1.0Vp-p, 75Ω |
| video output | 1 CVBS, 1.0Vp-p, 75Ω,Aviation,Support 1CH Full Screen,4CH Screen view | |
| preview |
Support 1 channel and 4 channels preview., Support Manual/Alarm Trigger full screen preview |
|
| resolution | 720P/D1/HD1/CIF, MAX:4 channels of 720P and 4 channels of D1 | |
| image quality | 1-4 levels, 1 is the highest level. | |
| video standard |
PAL: 100f/s , CCIR625 line,50field; NTSC: 120f/s, CCIR525 line,60field; CIF: 256Kbps ~ 1.5Mbps, 8 level video quality optional; HD1: 600Kbps ~ 2.5Mbps, 8 level video quality optional; D1: 800Kbps ~ 3Mbps, 8 level video quality optional; 720P: 4Mbps-6Mbps, multi level video quality optional |
|
| record mode |
The default setting is auto recording after power on. Timed recording, alarm trigger recording and manual recording are supported. |
|
| Audio | audio input | 4CH Aviation Plug Input |
| audio output | 2CH,headphone connect at front panel, BNC Connect on Back panel | |
| compression | G.726 compression, 8KB/s speed | |
| Alarm Input | 7CH Alarm Input,1CH AD Input,impulse speed input,Alarm Linkage | |
| Alarm Output | 2CH Alarm Output,Support Light/Sound alarm sensor,Oil/Power cut off | |
| Interface | 3CH RS232, POS/Fuel Sensor/LED Advertisement Connection | |
| 1CH 485 Interface,Connect PTZ Camera | ||
| Wireless Transmission |
Support Built in 3G transmission,, WCDMA, CDMA2000,GPRS, EDGE; Built in 4G module optional, TDD-LTE, FDD-LTE |
|
| GPS Position | Support Built GPS/BD Module | |
| Storage | HDD | Max 2.5” 1TB HDD |
| SD Card | Max 128GB SD Card Mirror Recording Keep Data Safety | |
| update | Support USB Updating, SD Card Updating,OTA Remote Updating | |
| file format | H.264 | |
| file system | Special FAT32 File System | |
| USB | USB Interface on Front Panel for data back up by U Disk,Hard Disk | |
| Record Replay | video search | Search By Record Time/Record Type etc |
| playback | Max support 4CH Replay /Stop/Fast/Slow at same time | |
| Support forward and backward play at the speed of: x 2,x4,x8,x16. | ||
| Security | User/Admin 2 Level Different Password | |
| Optional Functions | voice call | Support voice call each other |
| TTS Voice broadcast | Support TTS voice broadcast function. | |
| serial expand |
Support LED Advertisement Panel,Oil Sensor, POS,Bus Station Broadcaster,Car OBD,ect.external device |
|
| Voltage & Power | Power Management | Wide Voltage.Support Timed/Delay off |
| Input Voltage | DC:+6V - +36V | |
| Output Voltage | +12V~1.5A,+5V~1.5A | |
| Power | Working<5W | |
| Working Environment | Temperature | -20℃ - +70℃ |
| Humidity | 20% - 80% | |
| Others | Size | 200 (D)* 187(W)* 62(H) mm |
| Weight | 1.90Kg | |
working system
MDVR operating interface
CMSV6 Interface
CMSV6 In Mobile Phone
Have all in the palm of your hand
Real-time monitoring via Mobile Phone
Support iPhone, Android, iPad system
Video & Audio Monitoring: Online Vehicle + GPS
Satellite Map: Video Storage
PTZ control : Tracking Display
Picture Snapshot: Voice intercom
OEM Service: OEM and ODM services is accepted and welcome.
Delivery Time:3-5 working days for sample, bulk order 7-15days after received payment/order confirmed
Quality Warranty: 2 years for free repair. Whole life service for continue cooperating customers!
Delivery Term: By Express(DHL/FEDEX/TNT/UPS/EMS/CHINA POST),By air,By Sea.
FAQ:Q: How long is the warranty?
A: 12 -months-warranty since delivered out.
Q: What's the MOQ?
A: 1pc for sampe, at least 10pcs for bulk order after sample order.
1,what is payment term?
we can accept T/T,Western Union,Paypal,Bank Transfer,L/C and so on,you can choose one of them.
2,what's the trade term?
30% T/T in advance for deposit,the balance should be cleared before shipment.
3,Sample time
3-5days after sample fee and sample details confirmed.dispatch/send it by DHL/UPS/TNT/Fedex or by sea/by air/by special lines.
4,delivery date
5-15days after deposit and order details confirmed.
5,Shipment
we can delivery goods by air,by sea,by truck,etc.
6,package
1pc/box,1box/carton,by standard box and carton,packing method can be as per your request.
Feedbacks from customers:
1)This supplier has good softwares ability and can meet my needs. The sample works very good.
I am hoping to order more.
------- Davide from USA.
2)The cooperation is satisfied. The products are good. Very strong housing case.
My clients like a lot.
------- Tony from Russia
3)We made correct decision in choosing this supplier. We are now having much better
management and control on our vehicles. The ticket cash are more each day.
-------- Jose from Columbia
We will invite more customers to make comments and attach here.
we can offer customer whole service from mdvr setup,camera setup,PC/phone monitoring,CCTV display etc.
1),packaging detail
1pc/box,1box/carton,by standard box and carton,packing method can be as per your request.
2),Shipping detail
we can delivery goods by air,by sea,by truck,etc.
3),Sample time
3-5days after sample fee and sample details confirmed.dispatch/send it by DHL/UPS/TNT/Fedex or by sea/by air/by special lines.
4),goods delivery date
5-15days after deposit and order details confirmed.
5),what is payment term?
we can accept T/T,Western Union,Paypal,Bank Transfer,L/C and so on,you can choose one of them.
6),what's the trade term?
30% T/T in advance for deposit,the balance should be cleared before shipment.
Shenzhen Richmor Science&Technology Development Co.Ltd,who is a professional CCTV mdvr manufacturer for all kinds of Vehicle Mobile DVR in Shenzhen city,China.we have strong engineering team at our factory and have our own cutting-edge softwares for Server, Platform and Terminal devices.
All are A-one quality and Copyright protection.we are specialized in developing,manufacturing and selling intelligentized digital CCTV monitoring products.
1)products mainly:3G/4G mobile DVR,Network/Analog Million pixels high definition SD card/HDD mobile DVRs,3G/4G portable DVRs for Law enforcement,
2)cameras:CCTV car night viewing HD PTZ camera,analog car cameras,car high definiton cameras and other professional car CCTV equipments,OEM/ODM service is welcome.
3)customers from oversea: USA,Europe country,Australia,south afria,middle east,India,pakistan,new zealand etc with good cooperation
4)Advantage:Top Quality,reasonable factory price,wholesale Price with discount, Service good, Delivery fast.
- Welcome to our factory to discuss in details for more margins, better functions, and more reliable solutions.
Our factory workshop:
FAQ:
1.Q:Are you factory manufacturer or trade company?
A:We are factory manufacturer,we have our own factory and technology/skill support,we have engineers to support/take charge of R&D ,resolve problems product.
2.Q: Does the MDVR support Hard drive and SD card?
A: Yes, HDD version MDVR supports SSD, HDD, and SD card. SD card version MDVR supports max 2 SD card.
The storage capacity can be from 32GB to 2TB.
3.Q: Is it difficult to install MDVR into the vehicle?
A: Actually it is easy to install it into vehicle. Most driver can figure out how to connect the power cables.
And the camera installation is more easy. Just screw, connect and mount on the target place inside the vehicle.
4.Q: If I need door open and close alarm, overspeed alarm, reverse video, brake video, left-turn video, right-turn video, etc,is it available?
A: Definitely yes!
The I/O RS232 and 485 extension port is for all expanded purposes, including the functions above.
In fact, there are more customized functions which can be connect through this port, such as Fuel sensor, Counter system,PTZ camera, and so on.
5.Q: We have our own platform and server, can we use your MDVR? Do you have SDK or can you do customized platform for us?
A: Yes, we have SDK ready and welcome your OEM customized order!
6.Q: I ever bought MDVR from other supplier. But the anti-vibration is not strong. Now the MDVR works bad and video recording is not good. I am adfraid to buy again.
A: This happens. Vehicle Mobile DVR has to stand the rough bumping situation in the vehicle. So it is vital and important for MDVR to have strong anti-vibration struction, design, materials, software and function.
Not many factory can do this well.
We Sodimax factory has realized this shockproof function and our MDVR definitely&stably stand rugged and fast bumping in transit.
You can refer to our world classic shockproof video by this link:
7.Q: How about the 3G setting, and the WIFI setting?
A: The setting for MDVR is very important. Most functions need correct setting before use.
The 3G setting depends on the Telecommunication company and rules in local country.
Normally a simple call to your local telecommunication company can know the APN setting.
WIFI setting is more easy. Just input the same data with Wireless router and server.
8.Q: Does the MDVR come with accessroy, such as HDD, SD card, Microphone, Camera, Extension cable etc?
A: We have all accessories ready. You can ask us to make the complete quote for one whole set.
Normally the MDVR doesn't include any accessroy. Therefore it is advisable to inform us about your target accessory. All are can done right here. One-stop-serve purchasing.
9.Q: Can I get a sample to test before formal order?
A: Yes, you can.
We can provide sample with 1 month test period.
It will demand some deposit and the delivery(both send and resend) cost is supposed to be on your own side.
If the deliver cost is not so high, we recommend this way.
If not, then we do not recommend you do this.
Do not forget the import tax as well.
10.Q: How many camera in one set? Can I use my own accessory?
A: The accessory depends on you. The normal quotation is based on MDVR only.
The accessory would not be quoted until you ask for them.
And it is oK to use your own accessory. It is compatible.
11.Q: What can I do if the MDVR fails to work?
A: You can send it back to us. Remember that we provide 12 months quality warranty under normal use.
If you send it back, we will inspect the MDVR in details and repair it for you.
However we seldom have returned defective MDVR. The quality is rather good!
