Military Rank for 5ch 1080P DVR Vehicle cameras with good service for Night vison

Name: Military Rank for 5ch 1080P DVR Vehicle cameras with good service for Night vison
Brand: OEM/Richmor
Price: USD $75 - 300 / Piece

FOB Price

USD $75 - $300 / Piece

1 Piece(Min.Order)

Supply Ability 10000 Piece / Pieces per Month
Port Shenzhen or as you request
Payment Terms:Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:

Guangdong, China

Brand Name:

OEM/Richmor

Model Number:

RCM-MDR7105 series

Product Description

Our Company

Factory

Our Factory

Team

Our Team

Our company

Office & Worker

Trade show

Our show in Shenzhen

Product Description

RCM-MDR7105

MAIN FEATURES

1. HIS Solution,H.264 Compression,multiple stream recording,support 5CH video input, video recording and playback (4CH real-time 720p million pixels Analog HD input /4CH analog standard definition input/2CH analog input+2CH HD mixed input + 1CH 1080P network camera input);
2. 3CH video output (2CH CVBS video output,Support front and rear output; 1CH VGA output for optional )

3. Exclusive pre-allocate DVR Special File System Technology,Solving repeatedly wipe cause file fragmentation, solving storage file system crash, data loss and cannot find storage media and file garbled, ensure the integrity of the data.
4. 8-36V wide voltage with low power consumption. Support Reverse Protection、over-voltage/over-current protection.Output max to 10Amps current, support 12V & 5V peripheral equipment power supply. Ultra low power design;
5. Unique UPS Technology ensures the integrity of record when power failure occurs,even can last for 8-10s.
6. HDD+SD Card Storage ( Support 2.5” HDD, max 128G SD Card) protect from Shock & Dust damage;support USB port data backup and device update;
7. Support 2 USB ports, data backup and equipment upgrades.
8. Support 9CH alarm input (1CH Analog input + 8CH IO alarm input),2CH Independent alarm output.
9. Support 2 CAN interface.
10.Support HDD heating functions,can work in harsh environment.
11.Support GPS/BD/G-Sensor Extension module;
12.Realize real-time monitor through 3G/4G;
13.Support Broadcast/Intercom/Text sent etc;can add oil sensor/temperature sensor/POS/LED Advertisement Panel;
14.Support OTA device upgrade automatically, device can automatically upgrade version update, maintenance is more convenient

15.Support IOS/Android Phone Remote monitor
16.High reliability aviation connectors, high cost performance, stable and reliable.

Item	Parameter
OS	Linux
Language	English/Chinese/Customized
Video Compression	H.264 Compression
OSD	Overlays information such as date time and vehicle ID
GUI	Graphical User Interface	Setup system parameters with the remote control.
Video Record System	Video Input	CH real-time 720p million pixels Analog HD input /4CH analog standard definition input/2CH analog input+2CH HD mixed input+ 1CH 1080P network camera input) ,aviation connector, 1.0Vp-p, 75Ω
	Video Onput	2CH CVBS output+1CH VGA output for optional,1.0Vp-p, 75Ω,
	Video Onput	Support 1CH Full Screen,4CH Screen view
	Resolution	1080P/720P/D1/HD1/CIF, MAX:4 channels of 720P + 1080P / 4 channels of D1
	Image Quality	1-4 levels, 1 is the highest level.
	Preview	Support 1 channel and 4 channels preview, 5 channels splice preview Support Manual/Alarm Trigger full screen preview
	Video Standard	PAL: 100f/s , CCIR625 line,50field; NTSC: 120f/s, CCIR525 line,60field; CIF: 256Kbps ~ 1.5Mbps, 8 level video quality optional; HD1: 600Kbps ~ 2.5Mbps, 8 level video quality optional; D1: 800Kbps ~ 3Mbps, 8 level video quality optional; 720P: 4Mbps-6Mbps, multi level video quality optional





	Record Mode	The default setting is auto recording after power on. Timed recording, alarm trigger recording and manual recording are supported.
	Record Mode
Audio	Audio Input	4CH Aviation Plug Input
	Audio Output	2CH,headphone connect at front panel, BNC Connect on Back panel
	Compression	G.726 compression, 8KB/s speed
Alarm Input		7CH Alarm Input,1CH AD Input,impulse speed input,Alarm Linkage
Alam output		2CH Alarm Output,Support Light/Sound alarm sensor,Oil/Power cut off
Interface		3CH RS232, POS/Fuel Sensor/LED Advertisement Connection
		2CH 485 Interface,Connect PTZ Camera
		2CH CAN interface
Wireless Transmission		Built in 4G module optional, TDD-LTE, FDD-LTE
Wireless Transmission		Support Built in 3G transmission,, WCDMA, CDMA2000,GPRS, EDGE；
GPS Position		Support Built GPS/BD Module
Storage	HDD	Max 2.5” HDD
	SD Card	Max 128GB SD Card Mirror Recording Keep Data Safety
	Update	Support USB Updating, SD Card Updating,OTA Remote Updating
	File Format	H.264
	File System	Special FAT32 File System
	USB	USB Interface on Front Panel for data back up by U Disk,Hard Disk
Record Replay	Video Search	Search By Record Time/Record Type etc
Record Replay	Playback	Max support 4CH Replay /Stop/Fast/Slow at same time.Support forward and backward play at the speed of: x 2,x4,x8,x16.
Security		User/Admin 2 Level Different Password
Optional Functions	Voice Call	Support voice call each other
	Serial Expand	Support LED Advertisement Panel、Oil Sensor、POS、Bus Station Broadcaster、 Car OBD,ect.external device
	Serial Expand
	TTS Voice Broadcast	Support TTS voice broadcast function.
Voltage & Power	Power Management	Wide Voltage.Support Timed/Delay off/over-load/Reversing connection/voltage shortage/short circuit etc.
	Input Voltage	DC:+6V - +36V
	Output Voltage	+12V 1.5A，+5V 1.5A
	Power	Working ＜5W
	Temperature	-20℃ - +70℃
Working Environment	Humidity	20% - 80%
Working Environment	Size	200 （D）* 187（W）* 62（H） mm
Ohters	Weight	1.90 Kg

Products Show

Our Service

SATISFACTON

Powerful R&D team
Industry experience for Several years
Complete product range
Excellent quality and competitive price

24 hours service

Support all vehicles

We can offer customer whole service from mdvr setup,camera setup,PC/phone monitoring,CCTV display etc.

Excellent service

Professional sales service and after-sale service
High efficiency to meet your requirements
Customized service(ODM and OEM are welcome)

Our Certifications

We are professional OEM Mobile DVR and NVR produtor and company.

There are more certifications in our company.Such as RoHs,FCC,CE etc.

Packing & Delivery

Packing Details : 1pc/box,1box/carton,by standard box and carton,packing method can be as your request.

Delivery Details : We can delivery goods by air,by sea,by truck,etc.5-15days after deposit and order details confirmed.

1.Brand packaging

2. Box with Richmor

3. Neutral Box

4. Any Delivery way as you request

5. Standard accessories

6. Join Richmor

FAQ

Q: Are you trading company or manufacturer ?

A: We are factory manufacturer,we have our own factory and technology/skill support,we have engineers to support/take charge of R&D ,resolve problems product.

Q: How long is your delivery time?

A: Generally it is 5-15 days if the goods are in stock.

Q: Do you provide samples ? is it free or extra ?

A: Yes, you can.We can provide sample with 1 month test period.It will demand some deposit and the delivery(both send and resend) cost is supposed to be on your own side.If the deliver cost is not so high, we recommend this way.

If not, then we do not recommend you do this.Do not forget the import tax as well.

Q: Does the MDVR support Hard drive and SD card?

A: Yes, HDD version MDVR supports SSD, HDD, and SD card. SD card version MDVR supports max 2 SD card.
The storage capacity can be from 32GB to 2TB.
