price list of electronic sensor/electronic scale sensor
Discription of the linear position transducer
Place of Origin: Guangdong China (Mainland)
Brand Name: Hoersun
Model Number: KTM
Type: Rotary Potentiometer
Technology: Metal Foil
Resistance: 5K
Resistance Tolerance: 0.05%
Max. Operating Voltage: 24V
color: glivery
temperature: heat-resisted
speed: fast
Resistance:5 or 10 Kohms
Load resistance:mini 1 Mohms
Electrical measuring stock:75-1250mm
Mechanical specifications
Rod Material:S.S.-316
Rod dia:6mm
Case:paper tube
Protection:IP-67
Mechanical stroke:75 to 1250 mm
performance :Linearity :0.5% to 1%
Mechanical Life:10,000,000 cycle
Repeatability:0.05 %
Displacement speed:2m/s
Working temp:-20 to 80 degC
Main Specifications
| Pow supply | 18-30V DC,Current Drain:<50mA |
| Operation temperature | -40°C-75°C |
| Range: | From 0-25mm to 0-5000mm |
| Output | Analogue 4-20mA,0-5V,0-10V Start/Stop:RS485 Digital:Synchronous Series Interface(SSI) |
| Non-Linearity | <±0.05%FS |
| Repeatability | <±0.002%FS |
| Resolution | <±0.002%FS |
| Stroke Range: | 50mm-7000mm |
| Output Pulse | ≤20mV |
| Isolation | 500VDC (Power or output signal to housing) |
| Mechanical Zone | Null Zone:50.8mm Dead zone:63.5mm (Special Zone Please Contact Factory) |
| Rod Material | 304 or 316L Stainless Steel |
| Head Material | Casted aluminum or 316L Stainless Steel |
| Electronic Connection | 4 wire shield cable or Connector |
| Mounting | M18*1.5mm,M12*1.5mm,or Custom |
| Protecting Rate | Protection Rate:IP65 (or IP67) |
- Hydroelectric industry: Turbine and Gear in Hydro-electric power and Wind-power Generator;Throttle Valve Position
- Printing and Packing Industry;Paper Machine
- Woods Harvesting and Construction: Log Optimizer Positioning; Tile Compressing; Marble Cutting
- Port machinery; Container Handling
- Hydraulic Fluid Level Measurement, Wave Pool Level Measurement
- Fluid Power: Leveling Jacks; Valve Position
- Plastic and Rubber Part Manufacturing: Extrusion Rate; Tire Presses
- Tools; Woodworking, Metalworking and Assembly: Drill Press Stroke; Paint Sprayers
-
Model Price
EXW USDKFT-75MM 21.39 KFT-100MM 23.23 KFT-125MM 25.99 KFT-150MM 26.91 KFT-175MM 29.67 KFT-200MM 30.62 KFT-225MM 33.41 KFT-250MM 36.17 KFT-275MM 37.11 KFT-300MM 38.02 KFT-325MM 38.97 KFT-350MM 40.83 KFT-375MM 43.59 KFT-400MM 44.51 KFT-425MM 46.57 KFT-450MM 48.25 KFT-475MM 50.08 KFT-500MM 51.58 KFT-550MM 53.41 KFT-600MM 54.12 KFT-650MM 56.78 KFT-700MM 62.1 KFT-750MM 65.65 KFT-800MM 69.19 KFT-850MM 73.65 KFT-900MM 75.41 KFT-950MM 79.84 KFT-1000MM 85.17 KFT-1150MM 92.27 KFT-1250MM 96.7
