Digital Camera kit state id hologram 16CH CCTV DVR with 800TVL CMOS IR bullet Cameras dvr kit

FOB Price

USD $333.6 - $426.4 / Piece

10 Pieces(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Digital Camera kit state id hologram 16CH CCTV DVR with 800TVL CMOS IR bullet Cameras dvr kit

Camera Specification

Model No.	BE-ICD70	BE-ICD70S	BE-ICD100C	BE-ICD80M	BE-ICD80C	BE-ICD60	BE-ICD42
Image Sensor	1/3"Sony	1/3"Sony	1/3"CMOS	1/3"CMOS	1/4"CMOS	1/3"Sony	1/3"Sony
Image Sensor	ICX673BK CCD	ICX811AK CCD	PC1099	PC3089	MT9V139	ICX639BK CCD	ICX633BK CCD
Horizontal Resolution	700TVL, Low Illumination, DWDR, OSD, DNR, PM, MD	700TVL, Low Illumination, DWDR, OSD, DNR, PM, MD	1000TVL	800TVL	800TVL	600TVL, Low Illumination, DWDR, OSD, DNR, PM, MD	420TVL
Pixels	PAL: 976 (H)×494(V)	PAL: 976 (H)×582(V)	962 (H)×504(V)	762 (H)×504(V)	PAL: 720 (H)×576(V)	PAL: 795 (H)×596(V)
Pixels	NTSC : 976 (H)×582 (V)	NTSC : 976 (H)×582 (V)	962 (H)×504(V)	762 (H)×504(V)	NTSC : 720 (H)×480 (V)	NTSC: 811 (H)×508 (V)
Television Standards	PAL/ NTSC
IR LED	36PCS of 5mm IR LED
IR Distance	30m
Lens	Board Lens 3.6 mm/F2.0
Sync System	Internal
Usable Illumination	0.01Lux/F2.0
IR Power On	CDS Auto Control
S/N Ratio	≥65dB (AGC OFF)					≥54dB (AGC OFF)
Gamma Correction	0.45
Video Output	Composite Signal (1.0Vp-p, 75Ω)
Scanning System	PAL: 625 Lines, 50 Field/Sec; NTSC: 525 Lines, 60 Field/Sec
Electronic Shutter	Auto: PAL 1/50-1/100,000Sec; NTSC 1/60-1/100,000Sec
Operation Temperature	-10°C ~ +50°C, RH: 95% Max
Storage Temperature	-20°C ~ +60°C, RH: 95% Max
White Balance	Auto
Power Supply	DC12V
Dimension	135(W) x62(H) x120(D)mm

DVR Main Features:

DVR Specificatin:

	Model	BE-9016HC
System	Main processor	HIS chipset Hi3520D
Display	Display screen	1/4/8/9/16 screen
Video	Video standard	PAL(625 lines,50HZ);NTSC(525lines,60HZ)
	Monitor quality	Monitor:D1;VGA:1080P ;HDMI:1080P
	Playback quality	Max support 1080P under HVR and NVR mode;Max support D1 under DVR mode
	Encode capability	16CH CIF real time
	Decode capability	16CH CIF
	Motion detection	Each channel can set 192(16*12)detection area;can set multi-level of flexibility
Audio	Audio compression	G.711A
Record and playback	Record mode	Manual,alarm,motion detection,timing
	Local playback	Support 16CH CIF playback synchronously
	Video search	Time,date,event,channel search
Storage and back up	Space occupation	Video:CIF 4~5G/daychannel, D1 16~20G/daychannel; audio:691.2M/day*channel
	Video storage	Local HDD ,Network
	Back up mode	Network backup,USB portable HDD,USB DVD-RW,SATA DVD-RW
Interface	Video input	16CH BNC
	Video output	1CH BNC,1CH VGA,1CH HDMI
	Audio input	2CH RCA
	Audio output	1CH RCA
	Alarm input	4CH
	Alarm output	1CH
	Network port	RJ45 10M/100M self-adaptive Ethernet port
	PTZ control	1 RS485;support multi kinds of PTZ Protocol
	USB port	2*USB2.0
	HDD port	1 SATA(max support 3TB)
	Wireless port	3G,WIFI(extension via USB port)
CMS	CMS software	Support (up to 255 DVR simultaneously)
other	Tour	Support
	Remote controller	Support
	Working temperature	-20°C-60°C
	Working humidity	10%-90%
	Power	12V/3A
	Dimension	325(W) x52(H) x230(D)

Packaging & Shipping
