CNC Double Column band sawing machine
- 400 Set / Sets per Month
- ANY PORT IN CHINA
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Condition | New | Type | Band Saw | |
| Use | Metal Cutting | Style | Horizontal | |
| Place of Origin | Shandong, China | Brand Name | NO | |
| Model Number | GHS4228 | Usage | metal cutting / universal | |
| Voltage | 220/380V | Power(W) | 1500/2400W | |
| Dimension(L*W*H) | 1860*2400*1400 | Weight | 750KGS | |
| Certification | CE,ISO9001 | Warranty | ONE YEAR | |
| After-sales Service Provided | Overseas third-party support available |
Product Description
MAIN FEATURES:
1. Touch screen type control panel, sawing parameters digital setting 5 groups of sawing data;
2. PLC controller, flexible setting and conversion, combination between hand operation and automatic operation;
3. Double column structure vertical lifting high stability;
4. Cutting speed adopts hydraulic control, step less speed regulation;
5. Suited to batch saw cutting materials.
MODEL NO | GHS4228 | GHS4235 |
Cutting capacity | 280-280×280 | 350-350×350 |
Blade size | 3505×27×0.9 | 4115×34×1.1 |
Blade speed | 27 45 69 | 27 45 69 |
Clamping type | Hydraulic | Hydraulic |
Main motor power | 3 | 3 |
Motor hydraulic | 0.75 | 0.75 |
Coolant pump | 0.04 | 0.04 |
Overall dimension | 1860×2400×1400 | 2000×2500×1500 |
The production process :
Type of package: Plwood case
packing dimension:1860×2400×1400
certification:
PAYMENTS: 1.TT 30% advance payment product,pay the balance before delivery.
2.LC at sight.
COLOR, VOLOTAGE, POWER
