Specifications
High Speed Sheet Metal Slip Roll Bending Machine1.3 asymmetrical Rolls
2.With conical bending
3.Cam lock
4.CE,ISO9001
High Speed Sheet Metal Slip Roll Bending Machine ESR-1300X4.5
Main features:
1. Asymetrical roll bending machine with 3rolls
2. High strength steel rolls
3. Fixed top roller, adjustable lower and rear rollers
4. Worm gear and motor for prebending
5. Standard series wire core groove
6. Top roll swings out acr across cam lock
7. Supplied with conical bending featue
Specification:
| Model | Max rolling thickness (mm) | Max rolling width (mm) | Dia.of roll(mm) | Motor power (kw) | Packing size(cm) | N.W./G.W.(kg) |
| ESR-1300X1.5 | 1.5 | 1300 | 75 | 0.75 | 0.75 | 280/340 |
| ESR-1020X2 | 2 | 1020 | 60 | 1.5 | 174X70X126 | 260/325 |
| ESR-1300X1.5E | 1.5 | 1300 | 60 | 1.5 | 190X55X110 | 270/340 |
| ESR-2.5X1300 | 2.5 | 1300 | 90 | 1.5 | 200X72X120 | 540/560 |
| ESR-4.5X1300 | 4.5 | 1300 | 120 | 2.2 | 200X76X127 | 750/830 |
| ESR-3.5X1550 | 3.5 | 1550 | 120 | 2.2 | 200X76X127 | 790/890 |
| ESR-3.5X2020 | 3.5 | 2020 | 127 | 4 | 270X87X130 | 1100/1200 |
| ESR-1300X6.5 | 6.5 | 1300 | 150 | 3 | 282X87X134 | 1100/1190 |
| ESR-2070X2.5 | 2.5 | 2070 | 120 | 2.2 | 282X87X130 | 1050/1200 |
| ESR-2070X3.5 | 3.5 | 2070 | 127 | 3 | 282X87X130 | 1110/1250 |
Electric slip roll bending machine ESR-1300X4.5 production process:
Electric slip roll bending machine ESR-1300X4.5 machines in workshops:
Any questions you can inform me freely, Tel: 0086-0632-5810219
Skype: shaojie_2010
