E3-1N-1 Mini Electric Shear Press Brake and Slip Roll Machine
*Combination of shear , brake&roll.
*For shearing, lt can achieve single stroke and continuous stroke processing function.
*For bending, there are three function : Jogging single stroke and continuous stroke.
*For rolling there are two function; Jogging and continuous stroke.
*This machine is the ideal equipment for sheett-metal working.
Technical Parameters:
Model |
E3-IN-1/1320 |
E3-IN-1/2040 |
Max Shearing thickness(mm) |
3 |
3 |
Max shearing width(mm) |
1320 |
2040 |
Shearing angle |
2° |
2.5° |
Number of stroke(per min) |
30 |
30 |
Back-gauge range(mm) |
450 |
450 |
Height of worktable(mm) |
760 |
760 |
Max bending thickness(mm) |
2 |
2 |
Max bending width(mm) |
1320 |
2040 |
Max rolling thickness(mm) |
3 |
3 |
Max rolling width(mm) |
1500 |
2100 |
Min rolling dia(mm) |
90 |
120 |
Motor power(kw) |
3 |
4 |
N.W./G.W.(kg) |
2300/2800 |
3500/3800 |
Packing size(cm) |
254X145X197 |
326X145X197 |
Product Detail
E3-1N-1 Mini Electric Shear Press Brake and Slip Roll Machine
Wooden case, no need fumigation,plastic cover inside
We also would like to let you know our warranty about our new CNC horizontal turning lathe machine as following:
==about the machine break down, normally our policy will be as the under way
1) Our quality guarantee time is 12 months since the machine on board
2) During this period, if the machine break down owing our machine itself quality problem, we will prepare the spare parts and send to you by free within 5 days. all these will be by free.
3) If the break down is caused by the mis operation, we of course will supply you the spare parts, but we have to charge you the costs prices.
