Home > Products > Pipe Bending Machine > Hydraulic Section Bending W24-400,pipe Bending W24-400
Hydraulic Section Bending W24-400,pipe Bending W24-400
- Shanghai/Qingdao
- T/T
You May Like
-
Hydraulic Section Bending Machine W24Y-500,
-
Hydraulic Section Benders W24Y-500,hydraulic Benders W24Y-500
-
Hydraulic Section Benders W24Y-500,section Benders W24Y-500
-
Hydraulic Section Benders W24Y-500,three Rollers Benders
-
Hydraulic Section Benders W24Y-500,pipe Benders W24-400
-
Hydraulic Section Bender Machine W24Y-500,hydraulic Bender Machine W24Y-500
Product Details
| Condition | New | Place of Origin | Guangdong, China | |
| Brand Name | UNI-TECH | Model Number | W24-400 | |
| Machine Type | Roller-Bending Machine | Raw Material | Sheet / Plate Rolling | |
| Material / Metal Processed | Stainless Steel | Power | Hydraulic | |
| Automation | Automatic | Extra Services | Cut To Length | |
| Certification | ISO 9001:2000 | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
hydraulic section bending W24-400pipe bending
Bend l steel,flat bean, solid bar, etc.
CE,ISO9001
Hydraulic section bending W24-400
pipe bending
Features:
1.The machine is an efficient processing machine which is specially designed to bend l steel, flat bean, solid bar, etc.
2. It has three working rollers, the positions of the two bottom rollers can be adjusted along the arc.
3. Assisting rollers are installed on both sides of the machine to control the work quality in the bending of proportional steel sections.
4. The machine is reliable to operate with various functions and is an ideal bending machine thar's adjustable and able to deal with different types of materials and specifications only by recombining the die settings.
5.The machine offers low cost with flexibility and relibility.
6. Rolling easy.
Model | W24Y-400 | W24Y-500 | W24Y-1000 | |
Yield limit | mm | <245 | <245 | <245 |
Min. bending dia. (Angle steel leg out) | mm | 200-400 | 300-400 | 400-600 |
Capacity |
| L40X4 | L50X5 | L75X7 |
Overall size | L.mm | 1000 | 1200 | 1320 |
W.mm | 750 | 750 | 950 | |
H.mm | 1350 | 1580 | 1270 | |
N.W/G.W | kg | 500/600 | 900/1030 | 2500/2750 |
Main motor | kw | 2.2/1.5 | 2.2/2.2 | 4/2.2 |
Our machines has passed the strict CE certification and had already got the CE certificate. Our factory also get the ISO certificate.
