Full D1 hotsell 24CH tvt dvr/ outdoor HIS chipset Hi3531 DVR/ H 264 NVR/ P2P/ Cloud/ 1HDD/ CCTV DVR/ Real Time Networked
Specifications
ptz auto tracking camera outdoor
HIS chipset Hi3531
H.264
8CH D1+16CH CIF recording
8CH D1+8CH CIF realtime playback
1.Use the standard H.264 video compression format.’more advanced video compression technique makes the code stream lowered at least 30%
2.can realize 8CH D1+16CH CIF recording and 8CH D1+8CH CIF realtime playback Synchronously
3.Combines the functions of DVR/NVR together, multimode input ( support pure analog input,support pure network HD video input), just one can work
4.Support super cloud service (this function is optional, specialized website forsuper cloud service: ), one step to do remote control easily & conveniently without any complicated setting
5.Multiple operation simultaneously:Preview,recording,playback,backup,network live,mobilephone view
6.Multiple record mode:Auto,timer,motion recording mode
7.Optimized 16ch simultaneous playback ,each channel can be enlarge to full screen
8.Support backup with USB Flash Disk, Movable hard disk, DVD writer, Network
9.Support drag the progress bar can be targeted playback time directly
10.Support Network function:one IE browser centralized monitoring and CMS Software for multiple DVR
11.Supports Multiple backup mode: USB flash drive,USB hard disk and network backup
12.Support one SATA HDD, max capacity is 3TB
13.Support 3G & WIFI extension
14.Support multi-browser(IE,Chrome,Firefox,Safari)
15.Support mobile phone monitoring(iPhone,Windows Mobile,BlackBerry,Symbian, Android)
16.Powerful net service(support DHCP,PPPOE,FTP,DNS,DDNS,ARSP(),NTP,UPNP,EMAIL,IP authority,IP search,alarm center, etc),complete enclosure(WEB,CMS,SDK),to easily achie
Specification:
Model |
BE-9924HD |
|
System |
Main processor |
HIS chipset Hi3531 |
Display |
Display screen |
1/4/8/9/16 screen |
Video |
Video standard |
PAL(625 lines,50fps);NTSC(525lines,60fps) |
Monitor quality |
Monitor:D1;VGA:1080P ;HDMI:1080P |
|
Playback quality |
Max support 1080P under HVR and NVR mode;Max support D1 under DVR mode |
|
Encode capability |
8CH D1+16CH CIF real time(DVR mode) |
|
|
Decode capability |
8CH D1+8CH CIF real time(DVR mode) |
|
Multi-mode video input |
DVR mode :8*D1+16*CIF NVR mode:24*D1/20*960H/4*1080P/1*1080P+8*720P/2*1080P+4*720P+4 *960H |
Motion detection |
Each channel can set 192(16*12)detection area;can set multi-level of flexibility (for local analog channel only) |
|
Audio |
Audio compression |
G.711A |
|
Record and playback
|
Record mode |
Manual,alarm,motion detection,timing |
Local playback |
Max support 8CH D1+8CH CIF real time playback synchronously(DVR mode) |
|
Video search |
Time,date,event,channel search |
|
Storage and back up |
Space occupation |
Video:CIF 4~5G/day*channel, D1 16~20G/day*channel; |
Video storage |
Local HDD ,Network |
|
Back up mode |
Network backup,USB portable HDD,USB DVD-RW,SATA DVD-RW |
|
Interface |
Video input |
24CH BNC |
Video output |
2CH BNC,1CH VGA,1CH HDMI |
|
Audio input |
16CH RCA |
|
Audio output |
1CH RCA |
|
Alarm input |
16CH |
|
Alarm output |
4CH |
|
Network port |
RJ45 10M/100M self-adaptive Ethernet port |
|
PTZ control |
1 RS485;support multi kinds of PTZ Protocol |
|
USB port |
2*USB2.0 |
|
HDD port |
4 SATA(each max support 3TB) |
|
Wireless port |
3G,WIFI(extension via USB port) |
|
CMS |
CMS software |
Support (up to 255 DVR simultaneously) |
other |
Tour |
Support |
Remote controller |
Support |
|
Working temperature |
-20°C-60°C |
|
Working humidity |
10%-90% |
|
Power |
12V/6A |
|
Dimension |
443(L)x90(H)x458(W) |
