US$ 1,300 - 2,000
MOQ: 3 Sets
Key Specifications
Get Latest Price
Condition:
New
Type:
Horizontal
CNC or Not:
Normal
Payment & Shipping
Payment Methods:
Port of Shipment:
Any port in china
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hobby Metal Small Lathe CQ6123BUS$ 1,300 - 2,000MOQ: 3 Sets -
Manual Micro Bench Lathe 920WUS$ 1,300 - 2,000MOQ: 3 Sets
-
Hobby House Using Bench Lathe 920WUS$ 1,300 - 2,000MOQ: 3 Sets
-
DIY Precision Bench Lathe 920WUS$ 1,300 - 2,000MOQ: 3 Sets
-
Metal Hobby Bench Lathe 6123US$ 1,300 - 2,000MOQ: 3 Sets
Condition
New
Type
Horizontal
CNC or Not
Normal
Automatic Grade
Manual
Max. Swing Diameter
230mm
Place of Origin
Shandong, China
Brand Name
UNIECH
Model Number
CQ6123B
Voltage
220V, 110V
Power(W)
0.75KW
Dimension(L*W*H)
1060 x 550 x 550
Weight
95
Certification
ISO9001, CE
After-sales Service Provided
Overseas service center available
Specifications
DIY small lathe CQ6123Bgear drive DIY mini lathe
swing over bed 230mm
DIY small lathe CQ6123B
| Model | 920W | |||
| Max.Swing.over bed | mm | Φ230(9) | ||
| Max.Swing.over cross slide | mm | Φ130(5-5/16) | ||
| Bed width | mm | 115(4-1/2 ) | ||
| Max.Distance between centers | mm | 500(20 ) | ||
| Taper of spindle bore | MT#3 | |||
| Diameter of spindle bore | mm | Φ20(7/8) | ||
| Steps of spindle speeds | 6steps | |||
| Range of spindle speeds | r/min | 130-2000rpm | ||
| Metric thread range | mm | 0.4-3.5(18kinds) | ||
| Inch screw thread range | TPI | 8-60(30kinds) | ||
| Range of longitudinal feeds | 0.0006 -0.037 | |||
| Travel of tailstock quill | mm | 40(1-9/16 ) | ||
| Diameter of tailstock quill | mm | Φ26(1-1/16) | ||
| Taper of tailstock quill | MT#2 | |||
| Main motor power | 3/4HP, 1PH | |||
| Packing size of lathe(LxWxH) | mm | 1060 x 550 x 550 | ||
| Net Weight | Kg | 95 | ||
| Gross Weight | Kg | 130 | ||
