High Precision Universal Cylinderical Grinder M1432bx1000

Name: High Precision Universal Cylinderical Grinder M1432bx1000
Brand: unitech
SKU: 107448167
Availability: InStock

US$ 15,400 - 30,000 MOQ: 1 Piece

Key Specifications

Condition:

New

Type:

Cylindrical Grinding Machine

CNC or Not:

Normal

Tengzhou Uni-Tech Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Cylindrical Grinding Machine

CNC or Not Normal

Max. Grinding Diameter according to the client's requirement

Max. Grinding Length according to the client's requirement

Place of Origin Shandong, China

Brand Name unitech

Model Number M1432Bx1000

Voltage 220V/380V/400V

Power(W) 5.5KW

Dimension(L*W*H) 322X200X205CM

Weight 5.3MT

Certification CE ISO9000

After-sales Service Provided Engineers available to service machinery overseas

High Precision Universal Cylinderical Grinder M1432B
1.Converter headstock & Easy operation

High Precision Universal Cylinderical Grinder M1432B

High Precision Universal Cylinderical Grinder M1432B
1) Universal
2) Precise
3) With high rigidity
4) Reliable performance

Universal Cylindrical Grinding Machine M1432B

Introduction

MAIN SPECIFICATION		UNIT	M1432B
General capacity
Distance between centers		mm	1000, 1500, 2000, 3000
Center height		mm	180
Dia.Ground (O.D)		mm	8-320
Dia.Ground (I.D)		mm	30-100
Max.length ground (O.D)		mm	1000, 1500, 2000, 3000
Max.length ground (I.D)		mm	125
Max.weight of work piece		kg	150
Workhead
Swiveling angle			+90°
Center taper (MT)		MT	4
Spindle speed		r/min	50HZ:25-220 Stepless
Wheelhead
Wheel spindle speed		r/min	1670
Wheelhead rapid travel		mm	50
Max.travel		mm	246
Swiveling angel			±30°
Hand feed per.rev		mm	rough:2 fine:0.5
Hand feed per.gra		mm	rought:0.01 fine:0.0025
Wheel size (ODxWxID)		mm	400x50x203
Periphearal velocity		m/s	35
Internal grinding device
Spindle speed		r/min	10000/15000
Dimension of wheel		mm	max:50x25x13, min:17x20x6
Table
Hand feed per.rev		mm	6
Max.swiveling angle of table	Clockwise		3°(1000, 1500), 2°(2000, 3000)
	Anticlockwise		7°(1000), 6°(1500), 5°(2000), 3°(3000)
Longitudinal speed range of table		m/min	0.1-4
Tailstock
Center taper (MT)		MT	4
Quil travel		mm	30
Motor
Wheelhead motor power		kw	5.5
Internal grinding		kw	1.1
Workhead motor power		kw	1.5
Machine
Gross weight		kg	5.3(1000), 6.1(1500), 7.9(2000), 9.9(3000)
Packing dimension		cm	322x200x205, 422x200x205, 540x200x205, 739x200x205
