Wheel Head Moving Surface Grinding Machine

Name: Wheel Head Moving Surface Grinding Machine
Brand: UNI-TECH
SKU: 107447635
Availability: InStock

US$ 10,000 - 20,000 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Surface Grinding Machine

CNC or Not:

Normal

Tengzhou Uni-Tech Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

any port in china

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Surface Grinding Machine

CNC or Not Normal

Max. Grinding Length 300X1000

Place of Origin Shandong, China

Brand Name UNI-TECH

Model Number M7140A

Voltage 220V/380V

Power(W) 3kw

Dimension(L*W*H) 210x160x180cm

Weight 2300kgs

Certification ISO9001, CE

After-sales Service Provided Overseas third-party support available

Specifications

Wheel head moving surface grindingmachine
Standard with wheel flange, balancing arbor,wheel extractor,coolant tank and so on.

Wheel head moving surface grinding machine

Model		Unit	M7130	M7130A M7130AL	M7130B	M7130C	M7132	M7140	M7140A	M7140Ax1600
Code No.			301044	301045 301046	301047	301048	301049	301050	301051	301052
Worktable size(WxL)		Mm	300x1000				320x1000	400x1000		400x1600
Max matching dimension(W x L)		Mm	300x1000				320x1000	400x1000		400x1600
Max distance between spindle center line and worktable surface		Mm	575	575	975	1375	575	575	600
Longitudinal moving speed of worktable		m/min	3-27						3-25
T-slot number x W		Mm	3x18
Wheel head Cross moving	Continuous feed speed	m/min	0.5-4.5
	Intermittent feed speed	Mm/t	3-30
	Hand wheel feed	Mm/gra							0.02
Vertical Moving of wheel head	Rapid speed	Mm/min		400
	Hand wheel feed	Mm/.gra	0.005
Wheel Head motor	Power	Kw	5.5						7.5
	Rotation speed	Rpm	1440
Total power		Kw	8.63		9				11	13.5
Max loading capacity of worktable (with chuck)		Kg	470				500	620	620	1000
Chuck size(WxL)		Mm	300x680x1				320x1000x1	400x1000x1		400x800x2
Wheel size(ODxWxID)		Mm	350x40x127						400x40x127
Machine dimension(LxWxH)		Cm	286x154 x203	286x154 x203	286x154 x251	286x154 x293	284x164 x203	288x177 x203	311x182 x223	494x182 x223
Package dimension(LxWxH)		Cm	284x171 x213	284x171 x213	284x171 x261	284x171 x303	284x171 x213	295x220 x223	320x220 x233	500x220 x233
Machine Weight		t	3.48	3.5	3.7	4	3.6	4.7	5.01	6.51
