Help CenterRW-ETC-60 Cold Storage Temperature Controller
Related Products
-
Used Motor Professional RW-AT-1 Digital ThermometerUS$ 1 - 100MOQ: 10 Pieces -
Fluoropolymer Insulated CordsUS$ 1 - 5MOQ: 100 Meters
-
PVC Insulated CablesNegotiableMOQ: 100 Meters
-
High Performance Silica Fibre Insulated TapesNegotiableMOQ: 50 Pieces
-
Industrial Automation Digital Temperature ControllerNegotiableMOQ: 1000 Pieces
RW-ETC-60 is a temperature controller suitable for M.T. or L.T. ventilating refrigeration applications. Three-channel outputs control compressor, fan and electric heating or thermal defrost; Two sensors measure the storage temperature and evaporator temperature separately , NTC and PTC sensor can be exchanged; Celsius, Fahrenheit can be switch; Display Resolution is optional; Three menus may avoid unreasonably setting of the user; Support many kinds of digital input (door switch, exterior alarm, refrigeration/heating mode switching, pressure switch protection ,etc.), and copy key operation.
Specification:
2.1 Panel size: 75×34.5 (mm) Depth is 58 mm
2.2 Mounting size: 71x29 (mm)
3,Technical parameters:
3.1 Temperature measuring and controlling range:
NTC -50°C~120°C/-58°F~248°F
PTC -50°C~150°C/-58°F~302°F
3.2 Resolution: NTC 0.1°C/1°C/0.1°F/1°F
PTC 0.5°C/1°C/1°F
3.3 Accuracy:
NTC -50°C~70°C, ±1°C/±2°F
PTC -50°C~100°C, ±3°C/±5°F
3.4 Temperature calibration: ±10°C/±18°F
3.5 Power supply: 220VAC+10%/-15%;
110VAC+10%/-10%, 50/60Hz (optional)
3.6 Power consumption: ≤ 3W
3.7 Relay output capacity: Compressor:16A/250VAC
Fan:10A/250VAC Deforst:10A/250VAC
3.8 Environment temperature range: 0°C~60°C
3.9 Storing temperature: -30°C~75°C
3.10 Relative humidity: 20~85% (No condensate)
.
