Specifications
1.Large capacity2.Excellent quality
3.High efficiency
4.Precise performance
round tin can making machine
Semi-automatic round paint pail/food/beverage tin cans making machine/seaming machine
1.Main technical data.
Linear rate of welding |
6-18m/min |
Production capability |
20~80Cans/min |
Applicable can diameter |
ø65~ø176mm |
Applicable can height |
70~420mm |
Applicable material |
Tinplate Steel—based Temper:T2.5~DR8 |
Applicable material thickness |
0.18~0.35mm |
Seam welding landing |
0.4mm 0.6mm 0.8mm |
Seam point distance |
0.5~0.8mm |
Applicable copper wire diameter |
ø 1.38mm ø 1.5mm |
Cooling water |
Temperature:12~18°C Pressure:0.4~0.5Mpa Discharge:7L/min |
Power |
380V±5% 50HZ |
Total power |
18KVA |
Dimension |
1200×1100×1800mm |
Weight |
1200Kg |
2.Latest picture
******************************************************
*************************************************************************************************
3.Our major component suppliers
1, PLC(Programmable Logic Controller) is purchased from Japanese MITSUBISHI.
2, Low voltage apparatus are produced by SCHNEIDER.
3, IGBT(Insulated Gate Bipolar Transistor) is bought from Japanese FUJI.
4,OMRON is our sensor supplier.
5, HMI(Human Machine Interface) is purchased from WEINTEC Labs.,Inc in Taiwan.
4.Can making technology process
Cutting-----rounding-----welding-----coating-----drying-----pre-curling and expanding-----flanging-----seaming bottom-----beading and curling
5.Applicable types of cans
aerosol cans, food cans, beverage cans, chemical cans , paint pot and square bucket.
