Help CenterCastel Solenoid Valves
Related Products
About us
About product
Application
These valves are for Ammonia duty.The MSVA are pilot operated valves whilst the MDSA are direct operated solenoid valves.
They are used in many applications such as cold stores ,freezers,chilling applications etc.
Installation
They valves must be installed in horizontal positions with the coil housing no more than 45 degrees from the vertical position.
Construction
The valves is made up from various metals.Whilst stainless steel is used for components like strms,plungers,the main body is made from LCC .
| Type | Flanged Connection |
Port Size inches |
MOPD PSI |
Nominal Liquid Capacity T.R.- Ammonia Pressure Drop P.S.I |
Coll Ratlng | ||||||
| AC | 1 | 2 | 3 | 4 | 5 | Type | VOLT-HZ | Watts | |||
| MDSVA 12 | 1/2" | 0.14 | 250 | 8.0 | 11.2 | 13.5 | 16 | 17.5 | SVC-1 | 230AC 50/60 |
18 |
| MSVA 12 | 1/2" | 0.45 | 275 | 68 | 91 | 110 | 131 | 143 | |||
| MSVA 20 | 3/4" | 0.6 | 275 | 75 | 97 | 122 | 145 | 167 | |||
| MSVA 25 | 1" | 0.95 | 300 | 119 | 169 | 221 | 241 | 266 | SVC-2 | ||
| MSVA 32 | 1.1/4" | 1.075 | 300 | 125 | 174 | 225 | 249 | 277 | |||
| MSVA 40 | 1.1/2" | 1.26 | 300 | 275 | 390 | 500 | 550 | 625 | |||
