Help CenterFH18-52 Semi-automatic Canning Making Equipment/machine/machinary Quality Choice
Related Products
-
Manufacturing Machine for Round CanUS$ 30,000 - 40,000MOQ: 1 Set -
FH18-38 Semi-automatic Manufacture of Chemicals in China/machinery for FoodUS$ 30,000 - 40,000MOQ: 1 Set
-
Tin Can Manufacture EquipmentUS$ 30,000 - 40,000MOQ: 1 Set
-
Semi-automatic Canning MachineUS$ 30,000 - 40,000MOQ: 1 Set
-
Semi-automatic Can Body Welding Machine/tin Can Welding Machine/ Tomato Canning MachineUS$ 30,000 - 40,000MOQ: 1 Set
Specifications
1.High quality2.Easy to operate
3.Beverage can making machine
4.Can welding machine
5.dia:52-176mm
FH18-52 Semi-automatic canning making equipment/machine/machinary
1.Main technical data.
Linear rate of welding |
6-18m/min |
Production capability |
20-80 cans/min |
Applicable can diameter |
Ø52~Ø176mm |
Applicable can height |
70~500mm |
Applicable material |
Tinplate steel-based temper:T2.5~DR8 |
Applicable material thickness |
0.18~0.35mm |
Seam point distance |
0.5~0.8mm |
Seam welding landing |
0.4mm 0.6mm 0.8mm |
Applicable copper wire diameter |
1.38mm 1.5mm |
Cooling water |
Temperature: 12~18°C Pressure:0.4~0.5Mpa Discharge:7L/min |
Power |
380V±5% |
Total power |
18KVA |
Dimension |
1200X1100X1800mm |
Weight |
1200Kg |
2.Latest picture
*******************************accessories****************************************************
3.Our major component suppliers
1, PLC(Programmable Logic Controller) is purchased from Japanese MITSUBISHI.
2, Low voltage apparatus are produced by SCHNEIDER.
3, IGBT(Insulated Gate Bipolar Transistor) is bought from Japanese FUJI.
4,OMRON is our sensor supplier.
5, HMI(Human Machine Interface) is purchased from WEINTEC Labs.,Inc in Taiwan.
4.Can making technology process
Cutting-----rounding-----welding-----coating-----drying-----pre-curling and expanding-----flanging-----seaming bottom-----beading and curling
5.Applicable types of products
aerosol cans, food cans, beverage cans, chemical cans , paint pot and square bucket etc.
FH18-52 Semi-automatic canning making equipment/canning making machine/machinary
