HGMF-660-360 China thermoforming machine disposable cups machine
PICTURE OF THE MACHINE:
MAIN PART OF THE MACHINE:
final products:
Introduction:
HGMF-660-360 plastic tea cup making machine is a combination of mechanical, electrical and pneumatic components, and the whole system was controlled by micro Omron PLC. servo motor technology ensure high flexibility and low energy consumption, very low noise . It combines the material feeding, heating, feeding, forming, in-mould cutting and transporting into one process.
It is used for forming PP,PS,HIPS,PVC,and PET plastic sheets, which can be widely used to produce all kinds of plastic boxes, containers and other plastic wares, such as ice-cream cups, milk cups chocolate package boxes, candy boxes and fast-food boxes etc.
Suitable Sheet Materials |
PP.PS.PVC.ABC ,EPS |
Sheet Width range |
400-630mm |
Sheet Thickness |
0.3-2.00 mm |
Max.forming Area |
680×300mm |
Max.forming depth |
120mm |
Forming Pressure |
0.4-0.8mMpa |
Productivity |
25-35(stroke/min) |
Rated Heating Power |
100kw |
Total machine weight |
5000kg |
Water Temperature |
30℃ |
Dimension: |
4400 × 1450 × 2350mm |
Feeding sheet range |
100-400mm |
RUIAN HENG GONG PACKAGE MACHINERY CO.,LTD. Quality And Service is our culture. Specializes in manufacturing the most advanced plastic production line,
with a group of professional plastic machinery design and manufacturing personnel, has been committed to forming machine, sheet machine, plastic mold, plastic products design, manufacture and research and development.
Combined with 10 more years of experience in production of plastic products for the high energy consumption of the domestic plastic machine.
The drawbacks of the high labor-intensive low-yield and secondary pollution ... etc. and similar foreign models high price make it difficult for users to accept the status quo, developed a high-speed automatic with independent property rights in positive and negative pressure forming machine (thermoforming machine).The model is the automated production lines, to achieve the full sense of the molding, Punching, stacking and conveying a continuous automated production without human punching bring a lot of trouble, such as: security risks. The area, the second pollution. labor costs and the cost of electricity ... developed a patent on the invention fully enclosed oven, and previous plastic machine, energy consumption saving more than 60%, artificial lower by more than 80%, yield 2 - 3 times, the added quality of plastic products, to the maximum extent possible to reduce the price of the machine to achieve the highest.
Developed mode of punching, the quality of the product to achieve a qualitative breakthrough, the successful development of zero-gap forming products effective more than 90%. Our mold manufacturing level can reach the customers’ Fine, Difficult requirements.
please browse our website for more info.
https://img13.fr-trading.com/
Trade assurance:
Built to protect and safeguard your business
Warranty promise:
The product will enjoy a one-year warranty period from the date the commissioning of the product has proven acceptable.
Commissioning service:
After the product arrives at the client’s site, we will send technical personnel to work with the client for installation and commissioning, and train the operators and maintenance personnel of the client. Our technical personnel will leave the client’s site after client’s acceptance and signature.
Training service:
If the client sends its employees to receive training at our company, we will arrange for highly skilled personnel to train them and issue certificates to those who pass the examination. Generally, the training period is one week, during which period we will make arrangements for board and lodging.
Maintenance service:
Within the warranty period, if any problems that arise during client’s use of the product still cannot be solved under our remote assistance, we will send our technicians to the site for solving the problems within 72 hours upon receiving client’s notification. If the problems are not caused due to client’s operation, we will provide such service free of charge.
Lifelong service:
After the warranty period expires, our company will offer lifelong service to all contract-honoring clients and timely provide clients with spare parts, products and technical service at the most favorable price.
File service:
After the contract is implemented, we will establish files for clients, which include sales contracts, technical parameters, production task forms, commissioning reports and acceptance forms, relevant technical drawings, etc.
Note:
The above service promises only apply to domestic clients. Overseas clients shall bear all overseas costs.
Q1 : Why Choose HGPACKER?
A: HGPACKER got 10 mores years manufacturing experience. The most advantage is we got the most professional experts for after sale service, we will be patient and passionately to solve your problems.
Q2 : Are you a factory or trading company?
A: HGPACKER is a factory.
Q3 : Delivery time?
A: 30-60days after confirmation.
Q4 : What are the payment term?
A1:30% as deposit by T/T, and the balance before shipment.
A2:30% as deposit by T/T, and the balance by L/C at sight.
Q5 : What is the MOQ of this item:
A: 1 Set per style.
Q6 : Where is the loading port?
A: Ningbo Port
Q7: What is our company’s available production capacity?
A: Usually 60 sets per month.
Q8 : packing of the machine?
A: most of machine will pack with wooden case or rustproof packing.
