The NZSX-II ritual killing box is mainly used for slaughtering cattle and other livestock. First live cattle through cattle pathway rushed to kill box rotating body; close the tail gate, left and right clamping plate to the corresponding position, the clamping force should not be too large (clamped tight easily injured animals); the tail push plate is opened; the tail slide plate forward to a proper position; then lift bracket; slide plate clamping head rises to a certain height; start rotating to the slaughter position slaughter phlebotomy. After waiting for 5-10 seconds; the back support frame first released in place; working overtime again open at the same time the left splint also together to advance in place, to the effects of auxiliary pushing cattle. The cattle slipped into the bullpen after falling, twisting the reset button to reset to the initial state, and then proceed to the next step.
Reducer motor |
type |
YXRF77-Y100L4-BMG(M3) |
gear ratio |
i=52.07 |
|
Motor power |
3kw |
|
Hydraulic unit |
As attached figure |
|
Voltage and current |
380V,22.4A |
|
Phase and frequency |
Three phase,50Hz |
|
Capacity |
30 heads/ hour |
|
Total weight |
4500kg |
|
Overall size |
3020*2200*2600(except for collecting grid) |
|
