Help CenterPlywood Sliding Table Saw Automatic Edge Saw for Woodworking Door Four-sides Cutting Saw Machine
Related Products
-
Wood Circular Saw Woodworking Machine Wood SawUS$ 1,380 - 1,500MOQ: 1 Set -
Wood Cutting Saw China Panel Saw Panel Cutting SawUS$ 15,800 - 16,000MOQ: 1 Set
-
Woodworking Panel Saw Automatic Edge Saw for Woodworking Plywood Cutting MachineNegotiableMOQ: 1 Set
-
Woodworking Precise Mdf Panel Saw MachineUS$ 12,550 - 12,800MOQ: 1 Set
-
Radial Arm Saw Machine for SaleUS$ 1,980 - 2,100MOQ: 1 Set
| Name | Double end cutting saw |
| Model number | FU-48E |
Max.sawing size | 2440×1220mm |
| Min.sawing size | 1200×600mm |
| Max.cutting thickness | 60mm |
| Traction power | 0.65/0.85kw×3 |
| Sawing power | 4×(4kw+0.5kw) |
| Saw speed | 5600r/min |
| Saw size | 14” |
| Min.saw size | 4'' |
| Feeding power | 0.55kw |
| Weight | 4000kg |
| Overall dimension | 4900×3750×2250mm |
1. High-precision linear guide rail made-in-Germany supports steady movement and keeps itself long life.
2. PLC control system operated more easily.
3. The variable frequency and speed motor form Italy, with highest speed of 6000r/min, ensures the cutting plane more smooth and precise.
4. Saw positioning makes the cutting size more veracious by using German step motor and precision ball screw.
5. Workpiece are positioned and clamped by the electric eye and oil cylinder so as to obtain the best result.
6. Compare to normal saws, the horizontal and vertical saws of this machine, with double cutting efficieny. Saws are available to adjust to cutting different size of boards.
7. Essential equipment of woodworking industry.
1. 100%T/T ,30%T/T FOR THE DEPOSIT .70% BALANCE BEFORE SHIPMENT
2. IRREVOCABLE L/C AT SIGHT
3. WESTERN UNION
