Home > Manufacturing & Processing Machinery > Woodworking Machinery > Wood Boring Machine > Cnc Door Lock Hinge Hole Boring Machine
US$ 52,560 - 55,993
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
Normal
Motor Type:
Normal
Payment & Shipping
Payment Methods:
Port of Shipment:
ShunDe port China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Door Lock Body Making MachineryUS$ 52,560 - 55,583MOQ: 1 Set -
Wood Door Lock Drilling MachineryUS$ 52,560 - 55,533MOQ: 1 Set
-
Door Lock Installation MachineUS$ 52,500 - 55,533MOQ: 1 Set
-
Woodworking Door Lock-hole Drilling and Hinge Boring MachineUS$ 52,800 - 55,500MOQ: 1 Set
-
Different Kinds of Door LocksUS$ 45,800 - 46,300MOQ: 1 Set
Condition
New
CNC or Not
Normal
Motor Type
Normal
Spindle Speed
3500r/min
Place of Origin
Guangdong, China
Brand Name
FUNNG
Model Number
MDK45A-ZD
Voltage
380V
Power(W)
12kw
Weight
3000kg
Dimension(L*W*H)
3400x2000x1850mm
Certification
ISO9001:2000
Warranty
1 Year
After-sales Service Provided
Engineers available to service machinery overseas
| Name | Door lock & hinge drilling machine |
| Model number | MDK45-ZD |
| Clamping Size: | 2500mmx1000mm |
| Max. Working Thickness: | 30-65mm |
| Tatal Power: | 12kw |
| Total Spindle Quantity: | 9 |
| Drilling Spindle Speed: | 3500r/min |
| Milling Spindle Speed: | 18000r/min(can adjust) |
| Feeding Speed: | 25m/min(can adjust) |
| Feeding weight: | 200kg |
| Overall Dimension: | 3400x2000x1850mm |
| Weight: | 3000kg |
1. Using the servo feeder cutting, exact feeding avoid mistake
2. Using the "Y" direction feeder, automatic clamp fix position system, with exact fix positon, easy for the worker's movie the boards
3. Essential equipment of woodworking industry.
