58KHz AM EAS System AM01

Specifications

AM EAS System
1.EAS AM security system
2.largest detection range in line
3.Low false alarm rate
4.DSP,ASC&DMFD technology

58KHz AM EAS System AM01

EAS AM Antenna ,EAS Antenna , EAS System, Security System

Specifications:

1. Multi-antennas processing technology: a host can control three antennas.
2. Automatic adjustment: advanced environmental monitoring program, automatically search the environment noise.
3. Manual tuning: easy tuning and can be adjusted according to different environment and save the parameters.
4. Adaptive synchronization: avoid interference by adjusting the synchronization value.
5. Multi-channel processing technology: DPS processor can receive signals of multi-channels, reduce blind areas, and effectively improve the detecting range and rate.
6. Computer software tuning features: use special computer software to change parameters.
7. DSP processor with the use of advanced procedures, the system has strong anti-interference ability,

Parameter:

1. Antenna size: 150*38*13cm
2. Acrylic size: 129.5*38*2.5cm
3. Frequency: 58KHz±0.5KHz
4. Input voltage: 220V/AC OR 110V/AC
5. Power consumption: ≤45W
6. Detection range:1.0-2.4M (Depend on the environment and examined target)
7. Work environment: -20º C ~+55º C
8. Material: Imported Acrylic

Packing:

1. Standard: 1PC/Carton
2. Packing size: 167.5*48*14cm
3. Antenna G.W.: 25kg  N.W.: 21kg  Controller G.W.: 3.2kg
4. Controller size:38.5X34.5X18.5cm

Antenna

Material	PMMA
Input voltage	220V AC or 110V AC
Dimension	150x38x13cm
PMMA borad	129.5*38*2.5cm
Packing	168*48*14CM
Weight	25kg
Frequency	58KHz



Controller

Freq.	58KHz
Size	38.5X34.5X18.5cm
G.W.	3.2KG





PS:

1.The antenna should work with the a controller.

2.A controller can control three pieces of Antenna.











Update Date:2011-7-29 19:46:05
