Home > Industrial Equipment & Components > Power Transmission Parts > Transmission Belt > 1.5mm Nylon Base Flat Transmission Belt
1.5mm Nylon Base Flat Transmission Belt
US$ 28.00 - 40.00
MOQ: 50 Square Meters
Key Specifications
Get Latest Price
Standard or Nonstandard:
Nonstandard
Type:
Flat Belt
Material:
Other, Rubber & Polyamide film
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
1.5mm Blue Green Flat and Conveyor Belts and Nylon Base Power Transmission Belt Used for Textile MachineryUS$ 32.00 - 45.00MOQ: 50 Square Meters -
2.0mm Nylon Base Transmission Flat BeltUS$ 33.00 - 39.00MOQ: 50 Square Meters
-
2.0mm Nylon Layers Power Transmission Flat BeltUS$ 30.00 - 36.00MOQ: 50 Square Meters
-
GY-15N5 1.5MM Yellow/green Nylon Rubber Conveyor Belt Power Transmission Belt Dryer BeltUS$ 10 - 50MOQ: 50 Square Meters
-
3.5MM Yellow/green Automatic Lathes Belt Rubber Flat Power Transmission Belt High Energy Saving and Antistatic BletUS$ 5 - 150MOQ: 50 Square Meters
Standard or Nonstandard
Nonstandard
Type
Flat Belt
Material
Other, Rubber & Polyamide film
Place of Origin
Jiangsu, China
Brand Name
SEJONE
Model Number
GY-15N5
1.5mm nylon base flat transmission belt
Product Description
- TECHNICAL DATA
| ITEM NO. | GY-15N5 | ANTISTATIC | NO |
| THICKNESS (mm) | 1.5 | TRACTION LAYER MATERIAL | PA |
| BELT WEIGHT (KG/M2) | 1.77 | FRICTION COVER MATERIAL | NBR |
| MANUFACTURING WIDTH (mm) | 500 | FRICTION COVER COLOR | YELLOW |
| TENSILE FORCE FOR 1% ELONGATION PER UNIT OF WIDTH (N/mm) |
/ | REVERSE COVER MATERIAL | NBR |
| MIN PULLEY DIAMETER (mm) | / | REVERSE COVER COLOR | GREEN |
| WORKING TEMPERATURE (OC) | -20~80 | JOINING METHOD | THERMOFIX |
- DETAILED IMAGES
Package & Transport
Partners
Exhibitions
FAQ
More Belts Available
- MORE BELT COILS OR ENDLESS BELTS AVAILABLE
|
|
|
|
|
|
|
|
|
|
Recommend Products
ITEM NO. |
THICK NESS (MM) |
TRAC TION LAYER |
REVERSE COVER COLOR |
REVERSE COVER MATERIAL |
FRICTION COVER COLOR |
FRICTION COVER MATERIAL |
JOINING METHOD |
ANTI STATIC |
TEMPERA TURE (OC) |
MAX WIDTH (MM) |
HB-30N5 |
3.0 |
PA |
Blue |
NBR |
Blue |
NBR |
Thermofix |
× |
-20~70 |
500 |
HB-40N6 |
4.0 |
PA |
Blue |
NBR |
Blue |
NBR |
Thermofix |
× |
-20~70 |
500 |
HB-60N10 |
6.0 |
PA |
Blue |
NBR |
Blue |
NBR |
Thermofix |
× |
-20~70 |
500 |
H-LY-30N5 |
3.0 |
PA |
Light green |
NBR |
Yellow |
NBR |
Thermofix |
× |
-20~70 |
500 |
ITEM NO. |
THICK NESS (MM) |
TRAC TION LAYER |
REVERSE COVER COLOR |
REVERSE COVER MATERIAL |
FRICTION COVER COLOR |
FRICTION COVER MATERIAL |
JOINING METHOD |
ANTI STATIC |
TEMPERA TURE (OC) |
MAX WIDTH (MM) |
GY-10N3 |
1.0 |
PA |
Green |
NBR |
Yellow |
NBR |
Thermofix |
× |
-20~80 |
500 |
GY-12N4 |
1.2 |
PA |
Green |
NBR |
Yellow |
NBR |
Thermofix |
× |
-20~80 |
500 |
GY-15N5 |
1.5 |
PA |
Green |
NBR |
Yellow |
NBR |
Thermofix |
× |
-20~80 |
500 |
GY-20N8 |
2.0 |
PA |
Green |
NBR |
Yellow |
NBR |
Thermofix |
× |
-20~80 |
500 |
GY-20N6 |
2.0 |
PA |
Green |
NBR |
Yellow |
NBR |
Thermofix |
× |
-20~80 |
500 |
ITEM NO. |
THICK NESS (MM) |
TRAC TION LAYER |
REVERSE COVER COLOR |
REVERSE COVER MATERIAL |
FRICTION COVER COLOR |
FRICTION COVER MATERIAL |
JOINING METHOD |
ANTI STATIC |
TEMPERA TURE (OC) |
MAX WIDTH (MM) |
BK-10N3 |
1.0 |
PA |
Blue |
NBR |
Black |
NBR |
Thermofix |
× |
-20~80 |
500 |
BK-15N5 |
1.5 |
PA |
Blue |
NBR |
Black |
NBR |
Thermofix |
× |
-20~80 |
500 |
BK-20N8 |
2.0 |
PA |
Blue |
NBR |
Black |
NBR |
Thermofix |
× |
-20~80 |
500 |
MBR-20N5 |
2.0 | PA | Blue | NBR | Grey | NBR | Thermofix | × | -20~80 | 500 |
BR-20N10 |
2.0 | PA | Blue | NBR | Grey | NBR | Thermofix | × | -20~80 | 500 |
ITEM NO. |
THICK NESS (MM) |
TRAC TION LAYER |
REVERSE COVER COLOR |
REVERSE COVER MATERIAL |
FRICTION COVER COLOR |
FRICTION COVER MATERIAL |
JOINING METHOD |
ANTI STATIC |
TEMPERA TURE (OC) |
MAX WIDTH (MM) |
PT-GG-A |
1.5 |
PA |
Green |
NBR |
Green |
NBR |
Thermofix |
√ |
-20~80 |
500 |
PT-EG |
1.5 |
PA |
Red |
NBR |
Green |
NBR |
Thermofix |
× |
-20~80 |
500 |
TLL-8.0 |
8.0 |
PA |
Grey |
LEATHER |
Grey |
LEATHER |
Thermofix |
× |
-20~80 |
500 |
FL-R-30N6 |
3.0 |
PA |
Red |
Polyamide
Fabric
|
Grey |
LEATHER |
Thermofix |
√ |
-20~80 |
500 |
