Home > Products > New Products > carpenter machine transmission belt
carpenter machine transmission belt
- 1500 Square Meter / Square Meters per Month
- SHANGHAI
- Credit Card
Product Details
| Standard or Nonstandard: | Nonstandard | Type: | Flat Belt | Material: | Other, Nylon, NBR |
| Place of Origin: | Jiangsu, China | Brand Name: | SEJONE | Model Number: | LY-22N8 |
Product Description
- TECHNICAL DATA
| ITEM NO. | LY-22N8 | ANTISTATIC | NO |
| THICKNESS(MM) | 2.2 | TRACTION LAYER MATERIAL | PA |
| BELT WEIGHT(KG/M2 ) | 2.6 | FRICTION COVER MATERIAL | NBR |
| MANUFACTURING WIDTH (MM) | 500 | FRICTION COVER COLOR | YELLOW |
| TENSILE FORCE FOR 1% ELONGATION PER UNIT OF WIDTH (N/MM) | / | REVERSE COVER MATERIAL | NBR |
| MIN PULLEY DIAMETER (MM) | / | REVERSE COVER COLOR | LIGHT GREEN |
| WORKING TEMPERATURE(OC) | -20~80 | JOINING METHOD | THERMOFIX |
- DETAILED IMAGES
ITEM NO. | THICK NESS (MM) | TRAC TION LAYER | REVERSE COVER COLOR | REVERSE COVER MATERIAL | FRICTION COVER COLOR | FRICTION COVER MATERIAL | JOINING METHOD | ANTI STATIC | TEMPERA TURE (OC) | MAX WIDTH (MM) |
LY-15N5 | 1.0 | PA | Light green | NBR | Yellow | NBR | Thermofix | × | -20~80 | 500 |
LY-20N10 | 1.5 | PA | Light green | NBR | Yellow | NBR | Thermofix | × | -20~80 | 500 |
LY-25N12 | 2.0 | PA | Light green | NBR | Yellow | NBR | Thermofix | × | -20~80 | 500 |
LY-32N12 | 2.2 | PA | Light green | NBR | Yellow | NBR | Thermofix | × | -20~80 | 500 |
- Slitting & Cut to length
- Slitting & Open end
- Slitting, open end & skived
- Endless—Thermofix/wedge joint, Flexproof/finger
- Customized belt
- Plenty of stock belt available
More belt joint services as follows,
Q1: Manufacturer or Trading company?
A: 15 years specialized belt manufacturer.
Q2: Production capability?
A: 5000m2 each month for 200+ different belt items.
Q3: Production Line?
A: 6 automatic belt production lines, PLC controlled.
Q4: About R&D?
A: Yes, we have own R&D team. 8-10 items scheduled annually.
Q5: Material? Supplier?
A: polyamide film imported Toray, Japan; XNBR (rubber) imported from Germany. All suppliers authorized for 5 years and more.
Q6: Quality control?
A: Strict production flow and data to evaluate all steps; sheets track back each step.
Q7: OEM, ODM, Customized?
A: Sure. Not only color, design, texture, but also labeling, writing, marks and package.
Q8: Samples?
A: Sure, we offer free samples. Normally 3 working days.
Q9: Location & Visit?
A: 2 hours’ drive from Shanghai downtown, or 1 hour’s bullet train. Check below map. Call us, if you need us to pick up.
