Home > Manufacturing & Processing Machinery > Machine Tools > Drilling Machine > Drilling Machine

Drilling Machine

Name: Drilling Machine
Brand: TOSUNNY
SKU: 107289551
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

CNC or Not:

Normal

Place of Origin:

Zhejiang, China

Contact Supplier Request Quote Chat Now

Taizhou Taisen Mechanical Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

NINGBO

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

CNC or Not Normal

Place of Origin Zhejiang, China

Brand Name TOSUNNY

Model Number Z5035 / Z5035A

Voltage 24

Power(W) 55

Certification ce

After-sales Service Provided Engineers available to service machinery overseas

Drilling machne

This machine is designed for drilling, counterboring, reaming, tapping, spotfacing, etc. The maximum drilling capacity is 40mm on small or middle sized workpieces. It is widely used in machine works and repair shops for single piece or small lot production, having the features of abundant horsepower and high rigidity when compared with all the others of its kind at home and abroad.

Maximum drilling diameter	35mm
Taper of spindle hole	MT4"
Distance from the center of spindle to the surface of the vertical column	350mm
Maximum travel of spindle	180mm
Range of spindle speed	104-1450rpm
Maximum distance from spindle nose to base plate working surface	1320mm
Maximum distance from spindle nose to working table	770mm
Dimensions of working table	560×385mm
Dimensions of base	730×405mm
Width of T-slot	18mm
Distance of T-slot of working table	125mm
Distance of T-slot of base	150mm
Range of feed	0.1,0.2
Power of main motor	1.5kw
Power of coolant pump	60w
Overall dimension(L×W×H)mm	730×560×2220mm
Packing size(L×W×H)mm	1100×610×2270mm
Gross weight/net weight	595/545kg
