High Tech Result Oriented Drager Oxylog 1000 Available at Best Price
Negotiable
MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Breathing Apparatus
Brand Name:
Meditech Electronics
Model Number:
Drager Oxylog 1000
Payment & Shipping
Payment Methods:
Port of Shipment:
Delhi & Mumbai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
100% Safe Efficient Drager Oxylog 1000 for First Aid Vemtilation of Patient in EmergencyNegotiableMOQ: 1 Unit -
Compact Size Advance Transport Ventilator for Medical UseNegotiableMOQ: 1 Unit
-
Unique Design Electric Transport Ventilator for Intensive CareNegotiableMOQ: 1 Unit
-
Latest Technology Portable Transport Ventilator Having Great AccuracyNegotiableMOQ: 1 Unit
-
High Quality Tested Advance Efficient Air Compressor for VentilatorsNegotiableMOQ: 1 Unit
Type
Breathing Apparatus
Brand Name
Meditech Electronics
Model Number
Drager Oxylog 1000
Place of Origin
Delhi, India
Product Description
The Oxylog® 1000 offers first aid ventilation of patients in emergency situations. Designed to be used outdoors, its intuitive operation, robustness and transportability make the Oxylog® 1000 complete in its class. The ventilator has integrated audible and visual alarms that monitor both the airway pressure and supply pressure to aid in patient safety.
All functions are pneumatically operated, so the ventilator does not depend on any electrical power source. Thanks to its fundamental design, the Oxylog® 1000 also stands for great reliability, ready to meet rough conditions during your mission.
Technical data
- Oxylog 1000 – a time-cycled, volume controlled and pressure limited emergency ventilator for the controlled ventilation
- of patients who require a minute volume of at least 3 L/min.
- Dimensions (W x H x D) 215 x 90 x 215 mm / 8.5 x 3.5 x 8.5 inches (excl. handle)
- Weight 3.15 kg / 7.3 lbs
Drive Gas
- Medical grade O2 or in exceptional cases compressed air
- Supply pressure 2.7 to 6 bar / 40 to 88 psi at 60 L/min
Performance Data
- Ventilation mode IPPV/ CMV
- PEEP ventilation with optional PEEP valve
- Principle of operation Flow chopper
- Control Time-cycled, volume-constant
- Ventilation frequency, smoothly variable 4 to 54 1/min
- Minute volume, smoothly variable 3 to 20 L/min
- I:E ratio (fixed) 1 :1.5
- Max.airway pressure (Pmax), smoothly variable 25 to 60 mbar / cm H2O
O2 concentration of Ventilation Gas when O2 driven
- Switch to “Air Mix” approx 60% by vol. O2
- Switch to “No Air Mix” 100% by vol. O2
- Gas consumption of control approx 1.0 L/min
- Dead space volume approx 12 mL
- Device compliance approx. 1 mL/mbar / cm H2O
- Safety valve opening pressure 80 mbar / cm H2O
- Pressure gauge display –10 to + 80 mbar / cm H2O
Alarm Functions
- Supply pressure low (Psupply) Supply pressure drops below 2.7 bar / 40 psi
- Airway pressure high (Paw high) Actual value exceeds set value (Pmax)
- Airway pressure low (Paw low) A pressure of 10 mbar/cm H2O is not exceeded during inspiration
- The alarms are both visual and audible.
- They are provided by purely pneumatic components and do not require any power supply.
Conditions for Operation
- Temperature range –18 °C to +50 °C / 0 to 122 °F
- Relative humidity 15% to 95% rel humidity
- Ambient pressure 700 to 1100 h Pa
- Vibration tested in acc.with MIL STD 810 F, methode 514.5
- Airworthiness in acc.with RTCA DO-160 D, section 8
- Classification acc. to EC Directive 93/42/EEC Class IIb
- UMDNS Code 18-098
- Typical operating time MV = 10 L/min
- 2.5 L cylinder / 200 bar: approx. 90 min for "Air Mix", approx. 45 min for "No Air Mix"
- E-type O2 cylinder: approx. 112 min for "Air Mix", approx. 56 min for "No Air Mix"
- D-type O2 cylinder: approx. 64 min for "Air Mix", approx. 32 min for "No Air Mix"
