Heavy duty material jeans industrial sewing machine
About us:
Our company was established in March, 1993, and have more than 10 years' development. Our factory located in Shenzhen, covers an area of 4800 square meters. We are specialized in producing industrial sewing machines. In 2011, we passed ISO9001:2008 quality management system certification. We have established a comprehensive management system from model design and development, part production and assembly machine commissioning to after-sales tracking service. Our company has earned good reputation in China's sewing machine and accessory area.
Specification:
Direct-drive cutter crank arm type fell seam sewing machine
1. Suitable for sewing denim jacket with side seams, cuffs sewn seam, jeans.
2.Through the lab tug, it can feed strongly.
3.It adopts the top Direct-drive cutter crank and make it work very well.
4.It is made in arm type
Specifications:
Sewing form |
two needles six threads sewing machine |
|
Function |
medium~ high thickness: jeans, labor jacket, uniform |
|
Max sewing speed |
4500rmp |
|
Stitch length |
6.4mm(1/4”) |
|
Sewing length |
2.1mm~3.6mm(standard3.2mm) |
|
Needle/standard sewing |
UY130GS(standard)/Nm140(#22) |
|
Needle bar area |
33mm |
|
Stitch conductor |
6conductors |
|
Weight(head) |
23.5kg |
|
Presser foot lift |
Max9mm(6.5mmfor factory) |
|
Tug on the feed width |
11.9mm |
|
Feed adjustment method |
Main feed: slide length adjustments |
|
Poor feed: lever adjustment |
No poor feed |
|
Lubricating method |
Automatic rotary pump oil |
|
Machine oil |
Juki machine oil NO.18 |
|
Installation method |
Aid drive assembly MT103 mounted on the machine |
|
Standard accessory
Machine head, base, cleaner, table, stand and other necessary parts and tools.
Carton size: 67*37.5*49cm, Gross Weight:81.00Kg Packaged by hard foams inside, and cardboard box outside.
Why us:
1. We focus on researching and producing sewing machine since 1993.
2. We passed ISO9001:2008 quality management system certification.
3. We have 5 master technicians available during business hours if you have any Questions.
4. We offer special design services to meet your personal demands.
Warranty: one year long lifespan
