Feed-off-the-arm Chain Stitch High Copy Union Special 35800 Industrial Sewing Machine

Feed-off-the-arm Chain Stitch High Copy Union Special 35800 Industrial Sewing Machine

Features

Direct-drive cutter crank arm type fell seam sewing machine

1. Suitable for sewing denim jacket with side seams, cuffs sewn seam, jeans.

2.Through the lab tug, it  can feed strongly.

3.It adopts the top Direct-drive cutter crank and make it work very well.

4.It is made in arm type

Specifications:

Name                             QM-35800

Sewing form                  three needles six threads sewing machine

Function                        medium~ high thickness: jeans, labor jacket, uniform

Max sewing speed        4500rmp

Stitch length  6.4mm(1/4”)

Sewing length                          2.1mm~3.6mm(standard 3.2mm)

Needle/standard sewing      UY130GS(standard)/Nm140(#22)

Needle bar area            33mm

Stitch conductor           6conductors

Weight(head)                23.5kg

Presser foot lift             Max 9mm(6.5mm for factory)

Tug on the feed width  11.9mm

Feed adjustment method     Main feed: slide length adjustments

                                       Differential control: lever adjustment

Lubricating method      Automatic rotary pump oil

Machine oil                   Juki machine oil NO.18

Installation method      Aid drive assembly  MT103 mounted on the machine

What included in the box?
Machine head, base, cleaner, table, stand and other necessary parts and tools.Standard accessory

Watch video:

  /watch?v=vppvtG82EjM

Copy this link to youtube and watch video

Contact:
Email: leoho#  ( please change # to @ )

Ph/ WhatsApp:  +8618126328400

Wechat / Skype:  leoheyulei
