Hikvision 1MP ip Camera With Wifi and Poe

Model

parameters

nb01

1Megapixel CMOS PT Camera

Camera

Image Sensor

1/4" Progressive Scan CMOS

Min. Illumination

0.01Lux @(F1.2,AGC ON) ,0 Lux with IR

Shutter Speed

1/25 s to 1/100,000 s

Lens

4mm@ F2.0, Angle of view: 79° (2.8mm, 6mm optioanl)

Lens Mount

M12

Day &Night

IR cut filter with auto switch

Pan & Tilt

Pan:0° - 360°, Tilt: -15° - 90°

Digital Noise Reduction

3D Digital Noise Reduction

WDR

Digital WDR

Compression Standard

Video Compression

H.264 / MJPEG

H.264 encoding level

BaseLine Profile/Main Profile

Video Bit Rate

32Kbps~16Mbps

Audio Compression

G.711/G.726/MP2L2

Audio Bit Rate

64Kbps(G.711) / 16Kbps(G.726) / 32~128Kbps(MP2L2)


Max. Resolution

1280 * 720

Frame Rate

50 Hz: 25 fps (1280 x 720), 25 fps (704 x 576),

25 fps (640 x 480)

60 Hz: 30 fps (1280 x 720), 30 fps (704 x 576),

30 fps (640 x 480)

Image Settings

Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser

Backlight compensation

Yes, zone optional

ROI

Yes, up to 4 configurable areas

Network

Network Storage

NAS

Alarm Trigger

Motion detection, Dynamic Analysis, Tampering alarm, Network disconnect, IP address conflict, Storage full, storage error

Protocols

TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,

PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour

Standard

ONVIF, PSIA, CGI, ISAPI

General function

Flash-prevention, dual stream, heartbeat, mirror, password protection, video cover, watermark

Interface

Audio Input

1 built-in microphone

Audio Output

1-ch 3.5 mm audio interface, 1 built-in speaker

Communication Interface

1 RJ45 10M/100M Ethernet interface

Alarm input

1

Alarm output

1

Wi-Fi Specification(Only for the products with Wi-Fi module built-in)

Wireless Standards

IEEE802.11b, 802.11g, 802.11n Draft

Frequency Range

2.4 GHz ~ 2.4835 GHz

Channel Bandwidth

20/40MHz Support

Protocols

802.11b: CCK, QPSK, BPSK

802.11g/n: OFDM

Security

64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS

Transmit Output Power

11b: 17±1.5dBm @ 11Mbps

11g: 14±1.5dBm @ 54Mbps

11n: 12.5±1.5dBm

Receive Sensitivity

11b: -90dBm @ 11Mbps (Typical)

11g: -75dBm @ 54Mpbs (Typical)

11n: -74dBm (Typical)

Transfer Rates

11b: 11Mbps

11g: 54Mbps

11n: up to 150Mbps

Wireless Range

Outdoor: 200m, Indoor: 50m(depend on environment)

Wireless Standards

IEEE802.11b, 802.11g, 802.11n Draft

General

Operating Conditions

-30 ^.C– 60 ^.C(-22 °F – 140 °F)

Humidity 95% or less (non-condensing)

Power Supply

5V DC±10%

PIR

Angle: 80°

Range: 10m

IR Range

10 meters
