Help CenterM9208-xxx-x Series Electric Spring Return Actuator
Related Products
-
Manual or Automated Balancing DamperNegotiableMOQ: 100 Units -
Volume Control Damper (13 Gauge Frame)NegotiableMOQ: 100 Units
-
Forged Brass Ball Valves for Assembly in the FieldNegotiableMOQ: 100 Units
-
Cast Iron Flanged Globe ValveNegotiableMOQ: 100 Units
-
P1000 Series Pressure Independent ValvesNegotiableMOQ: 100 Units
Specifications
direct-coupled designelectronic stall detection
double-insulated construction
plenum rated models
5-year warranty
Description
The M9208-xxx-x Series Electric Spring Return Actuators provide control of dampers in Heating, Ventilating, and Air Conditioning (HVAC) systems. All actuators in this series provide 70 lb·in (8 N·m) rated torque.A mechanical spring return system provides rated torque with and without power applied to the actuator. The series includes the following control options:
• On/Off, 24 V, 120 VAC, 230 VAC power
• On/Off and Floating Point, 24 V power
• Proportional, 24 V power, for 0(2) to 10 VDC or 0(4) to 20 mA Control Signal
These actuators are configured for direct mounting and do not require a damper linkage. Actuators can be mounted directly to a damper shaft from 5/16 to 5/8 in.(8 to 16 mm) diameter with a universal clamp. For shafts up to 3/4 in. (19 mm) diameter use the accessory Large Shaft Coupler Kit M9208-600. An accessory crankarm and remote mounting kit are available for applications where the actuator cannot be direct-coupled to the damper shaft. Optional line voltage auxiliary switches indicate an end-stop position or perform switching functions within the selected rotation range.
Features
• 70 lb·in. (8 N·m) rated torque
• direct-coupled design
• reversible mounting
• electronic stall detection
• double-insulated construction
• microprocessor-controlled brushless DC motor (-AGx and -GGx types)
• external mode selection switch (-AGx and -GGx types)
• locking manual override with auto release and crank storage
• override control (proportional model only)
• integral cables with colored and numbered conductors
• integral connectors for 3/8 in. (10 mm) Flexible Metal Conduit (FMC)
• optional integrated auxiliary switches
• UL, CE, and C-Tick compliance
• manufactured under International Standards Organization (ISO) 9001 quality control standards
• 5-year warranty
