Help CenterWuzhoulong 35 Seats Tourist Diesel Bus
Negotiable
MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Seats:
Other, 24-39
Emission Standard:
Euro 4
Transmission Type:
Manual
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen or Shanghai port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
8.2m 35 Seats Diesel Engine Coach BusUS$ 51,500 - 60,000MOQ: 1 Unit -
Chins Produced 49 Seats Diesel Coach BusNegotiableMOQ: 1 Unit
-
7m 20-27 Seats Stock Mini Coaster Bus on SaleUS$ 21,000 - 22,000MOQ: 1 Unit
-
26 Seats Stock Bus For SaleUS$ 21,000 - 23,000MOQ: 1 Unit
-
35 Seats Tourist Coach BusUS$ 41,450 - 48,000MOQ: 1 Unit
Seats
Other, 24-39
Emission Standard
Euro 4
Transmission Type
Manual
Condition
New
Engine Capacity
6 - 8L
Fuel Type
Diesel
Place of Origin
Chongqing, China
Brand Name
Wuzhoulong
Model Number
WZL6890A4
Specifications
9m 24-39 Seats Tourist Diesel BusSize: 8990x2500x3580mm
Rated passenger: 24-39
Top speed:100km/h
Our products can be customized,
small order quantity is acceptable.
WZL6890A4 rear engine coach configuration
Overall Parameter
| Over all length (mm) | 8990 |
| Over all width (mm) | 2500 |
| Over all height (mm) | 3580 |
| Wheel base (mm) | 4300 |
| Front/rear over hang (mm) | 1940/2750 |
| Approach/departure angle (°) | 10/9 |
| Front /rear thread (mm) | 1940/1800 |
| Gross weight (kg) | 12200 |
| Rated passenger | 24-39 |
| Top speed | ≤100 |
Engine Parameter
| Model | YC6J220-42 |
| Manufacture | Yuchai |
| Position/fuel | rear/diesel |
| Type | Inline 6 cylinders,turbocharger-intercoller,4 strokes, electronically controlled common rail fuel injection system |
| Max power (ps/r/min) | 210/2200r/min |
| Max torque (N.m/ r/min) | 710N.M/1200-1700r/min |
| Displacement | 6.494 |
| Emission | Euro IV |
Chassis Parameter
| Type/manufacture | EQ6870RN4AC |
| Transmission | ZD.F5S800 Flexible shaft remote control |
| Cultch | Single, dry, diaphragm spring, disc diameterφ395,hydraulic remote control, gas booster |
| Front axle | Dongfeng DANA,4.2T, disc brake |
| Drive axle | Dongfeng DANA,8T,ratio of speed:4.875,Drum brake |
| Suspension | Leaf Spring |
| Steering | Power steering,, adjustable hand wheel,φ500 |
| Brake | Dual-circuit air brake with ECE standard, brake staff with front is disc and rear is drum, energy storage spring parking brake. |
| Oil tank | 200L |
| Tyre | 9R22.5-14PR,7 pieces (Trangle brand) |
| Battery/generator | 150Ah×2/150A 28V |
| Others | Copper tank with electromagnetic clutch fan, ABS, self-adjust arm |
Body
| Structure | Semi-monocoque |
| Inner decoration | Molding soften interior trim, top plate is 5mm wood board, side plate are PVC plate, soften dash board. |
| Door&door pump | Single remote keyless outer pendulum entry, electronically controlled pneumatic door pump, Security door on the left side. |
| Windshield&side window | Panoramic laminated front windshield, steel rear windshield, side window are bonding glass.( driver window, tail windows are aluminum frame sash window) |
| Review system | Rabbit ear rear-view with defrost |
| Heating system | Non-independence plumbing, 4 radiator/plumbing defrost |
| Video&audio system | MP3, reading lamp with a trumpet, 17 inch manual type LCD TV |
| Lamp | Front combination lamp, combined rear lamp, through type lamp strip of the inner dome light, the wind with reading lamp, aisle lights. |
| Wiper | Opposite type wiper with washer. |
| Seat | Vehicle 37+1+1. Luxury road car seat, adjustable backrest, safety door with a turnover type double chair, before and after, height backrest of adjustable driver seat. |
| Floor leather | wear-resisting floor leather |
| Lacquer | solid lacquer |
| A/C | independent overhead air-conditioning refrigeration capacity: 24000kcal/h, model BFFD-04. |
| Bin door | Aluminum alloy doors, turn type. |
| Others |
Electronic clock, Folding side curtains , front windshield , the driver window sunshade, Aluminum alloy wheel covers ( semi- cover ) , Fire extinguisher, Warning triangle 1pcs, Security hammer with alarm function 4 pcs, Color reversing monitor,bus monitor(2 cameras), Driving recorder with GPS function, Engine compartment automatic fire extinguisher with alarm function, The 920B type with ventilator skylights 1pcs
|
