Help Center9m 24-39 Seats Tourist Bus
Negotiable
MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Seats:
Other, 24-39
Emission Standard:
Euro 4
Transmission Type:
Manual
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen or Shanghai port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
11m 49 Seats Luxury BusUS$ 84,500 - 95,000MOQ: 1 Unit -
7m 20-27 Seats Mini Coaster For SaleUS$ 24,000 - 29,000MOQ: 1 Unit
-
6.6m 24-26 Seats Coaster PriceUS$ 24,000 - 28,000MOQ: 1 Unit
-
12 Meters 60 Seats Long Distance Coach BusNegotiableMOQ: 1 Unit
-
49 Seats Diesel Coach for SaleNegotiableMOQ: 1 Unit
Seats
Other, 24-39
Emission Standard
Euro 4
Transmission Type
Manual
Condition
New
Engine Capacity
6 - 8L
Fuel Type
Diesel
Place of Origin
Chongqing, China
Brand Name
Wuzhoulong
Model Number
WZL6890A4
Specifications
9m 24-39 Seats Diesel Tourist BusSize: 8990*2500*3580mm
Top speed:100km/h
With good quality and best price.
Our products can be customized,
small order quantity is acceptable.
9m 24-39 Seats Tourist Bus
Overall Parameter
| Over all length (mm) | 8990 |
| Over all width (mm) | 2500 |
| Over all height (mm) | 3580 |
| Wheel base (mm) | 4300 |
| Front/rear over hang (mm) | 1940/2750 |
| Approach/departure angle (°) | 10/9 |
| Front /rear thread (mm) | 1940/1800 |
| Gross weight (kg) | 12200 |
| Rated passenger | 24-39 |
| Top speed | ≤100 |
Engine Parameter
| Model | YC6J220-42 |
| Manufacture | Yuchai |
| Position/fuel | rear/diesel |
| Type | Inline, 6 cylinder, 4 strokes, high pressure common rail electronic injection. |
| Max power (ps/r/min) | 220/2200r/min |
| Max torque (N.m/ r/min) | 800N.M/1200-1700r/min |
| Displacement | 6.494 |
| Emission | Euro IV |
Chassis Parameter
| Type/manufacture | EQ6870R4AC |
| Transmission | ZD.F5S800, flexible manipulation |
| Cultch | Monolithic dry diaphragm spring, driven disc diameter φ 395, remote control, gas booster. |
| Front axle | Dongfeng DENA, 4200kg load capacity, drum brake. |
| Drive axle | Dongfeng DENA, 8000kg load capacity, 4.33 speed, drum brake. |
| Suspension | Multi Spring ,front9/rear 11 |
| Steering | Power steering, dual gimbal adjustable steering axle, steering wheel on the front and adjustable, steering wheel diameterφ 500 |
| Brake | In line with the ECE standard dual circuit brake, front and rear drum brake, the energy storage spring parking brake. |
| Oil tank | 200L |
| Tyre | 9R22.5-14PR 7PCS (Trangle brand ) |
| Battery/generator | 150Ah×2/150A 28V |
| Others | Copper water tanks, ABS, in self adjustment arm, gas control system. |
Body
| structure | Half bearing |
| Inner decoration | Molding soft interior, for 5mm top plank+fabric (snow white), side PVC plate, forming duct tape luggage rack, the softening instrument station( take a pair of station and the armrest.) |
| Door&door pump | Anterior single out, electric starting gate pump, remote control door lock, the safety door on the left side. |
| Windshield&side window | Panoramic laminated front windshield, tempered after stalls, side window for fixing glass(window, rear window driving around for the aluminum alloy frame sliding window) |
| Review system | Manual rabbit ear type rear view mirror. |
| Heating system | Water heating |
| Video&audio system | MP3, reading lamp with a trumpet, 17 inch manual type LCD TV |
| Lamp | Front combination lamp, combined rear lamp, through type lamp strip of the inner dome light, the wind with reading lamp, aisle lights. |
| wiper | Opposite type wiper with washer. |
| Seat | Vehicle 37+1+1. Luxury road car seat, adjustable backrest, safety door with a turnover type double chair, before and after, height backrest of adjustable driver seat. |
| Floor leather | wear-resisting floor leather |
| Lacquer | solid lacquer |
| A/C | independent overhead air-conditioning refrigeration capacity: 24000kcal/h, model BFFD-04. |
| Bin door | Aluminum alloy doors, turn type. |
| Others |
Electronic clock, Folding side curtains , front windshield , the driver window sunshade, Aluminum alloy wheel covers ( semi- cover ) , Fire extinguisher, Warning triangle 1pcs, Security hammer with alarm function 4 pcs, Color reversing monitor,bus monitor(2 cameras), Driving recorder with GPS function, Engine compartment automatic fire extinguisher with alarm function, The 920B type with ventilator skylights 1pcs
|
