U-beam

Name: U-beam
Brand: YongYang
SKU: 107141759

US$ 520 - 550 MOQ: 100 Metric Tons

Key Specifications

Standard:

Dimensions:

24.95kg/m

Grade:

20MnK,Q275

Hebei Yongyang Special Steel Group Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin Port China

Delivery Detail:

Delivery time depends on order quantity.

Standard GB

Dimensions 24.95kg/m

Grade 20MnK,Q275

Place of Origin Hebei, China

Brand Name YongYang

Model Number 25U

Shape U Channel

Application Minerals

Perforated Or Not Not Perforated

THE LIST OF YYGT

Name of Commodity	Specificaton	Materials	Standard of Products	Theory Weight	Length of Dimension (m)	Packed in bundle with iron wire (pcs/bundle)
Light Rail	4kg/m	Q235	Q/YYG001-2008	4kg/m	6,8,9,10	75
	8kg/m	Q235	Q/YYG001-2008	8.42kg/m		55
	12kg/m	Q235	GB11264-89	12.2kg/m		36
	15kg/m	55Q/50Q	GB11264-89	15.2kg/m		28
	18kg/m	55Q/50Q	YB222-63	18.02kg/m		21
	22kg/m	55Q/50Q	GB11264-89	22.3kg/m		21
	24kg/m	55Q/50Q	Q/YYG001-2008	24.46kg/m		21
	30kg/m	55Q/50Q	GB11264-89	30.1kg/m		15
Heavy Rail	38kg/m	U71Mn	GB2585-2007 Q/YYG002-2008	38.733	12,12.5	10
	43kg/m	U71	GB2585-2007 Q/YYG002-2008	44.653		10
	50kg/m	45Mn	GB2585-2007 Q/YYG002-2008	51.514		10
Crane Rail	QU70	U71Mn	YB/T5055-93	52.8kg/m	12,12.5	10
	QU80		YB/T5055-93	63.69kg/m		10
	QU100		YB/T5055-93	88.96kg/m		5
	QU120		YB/T5055-93	118.1kg/m		5
I-beam of Mine Usage Steel	9#	20MnK/ Q235	YB/T5047-2000	17.69kg/m	8,9,10	28
	11#		YB/T5047-2000	26.05kg/m		18
	12#		YB/T5047-2000	31.18kg/m		15
U-beam Of The Mine Channel Steel	25U	20MnK/ Q235	GB4697-1991 Q/YYG006-2008	24.95kg/m	8,9,10,12	15
	29U		GB4697-1991	29kg/m		15
	36U		Q/YYG006-2008	35.87kg/m		15

Name of Commodity	Specificaton	Materials	Standard of Products	Theory Weight (kgs/set)	Length of Dimension (cm)	Packed in bundle with iron wire (set)
Fish Plate	8kg	Q235B	GB11265-89	0.8 +0.8 =1.6		50
	8kg		GB11265-89	1+1=2		50
	12kg		GB11265-89	1.1+1.1=2.2	45.5	50
	12kg		GB11265-89	2.6-3.0	45.5	50
	15-18kg		GB11265-89	3.6-4.0	53.54	25
				4.6-5.0
				5.6-6.0
	22-24kg		GB11265-89	6.6-7.0	61.73	20
				7.6-8.0
				8.4-9.0
	30kg		GB11265-89	14.4-15.0	71.48	10
	30kg		GB11265-89	16.4-17.0	71.48	10
	43kg		GB185-63	57.0-58.0	79	1
