Specifications
3 function:TIG/MMA welding and air plasma cutting110/220 double voltage input
multifunction welder CT 520D
- Three-in-one 50A plasma cutter, 200A tig welder and 180A stick welder
- Automatic Dual Voltage (110VAC/220VAC) Dual Frequency (50Hz/60Hz)
- Input Voltage: 110vac ~220vac (Auto detected, no switch is necessary)
- Input Power Frequency: 50 hz / 60 hz (Better performance under 60 hz)
FEATURE of DC TIG/MMA/CUT multifunction welder [CT 520D]:
1. Advanced inverter technology, reduced size and weight, easy to carry.
2. Novel and effecitive, and low cost;
3. Three functions in one machine, tig welding, mma welding and air plasma cutting
4. Compact and easy for operation.
5. 'D' Series are for 110/220 duel voltage input, automatic input voltage changing
6. Complete accessories: Welding torch, welding cable(3 m), earth clamp, welding holder, cutting torch, carton box
7. Fan-cooled, Thermostatic protection, suitable for DIY and family use.
Parameters of DC TIG/MMA/CUT multifunction welder CT 520D:
|
Model Spec. |
CAT-520D |
Power supply voltage |
AC 110/220 v±10% V / 50~60Hz |
Power supply capacity |
3.6 kVA |
Rated input current (TIG) |
16.7 A |
Rated input current (MMA) |
23 A |
Rated input current (CUT) |
27 A |
Output current range (TIG) |
10 - 200 A |
Output current range (MMA) |
10 - 200 A |
Output current range (CUT) |
25 - 50 A |
No-load voltage (TIG) |
56 V |
No-load voltage (MMA) |
56 V |
No-load voltage (CUT) |
220 V |
Operating voltage (TIG) |
17.2 V |
Operating voltage (MMA) |
27.2 V |
Operating voltage (CUT) |
160 V |
Dia. of welding rodΦ(MMA) |
3.6 mm |
Arc initiation way (TIG) |
HF |
Arc initiation way (MMA) |
Touch |
Arc initiation way (CUT) |
HF |
Protection grade provided by enclosure |
IP 21 |
No-load loss |
50 W |
Cosφ (η) |
0.93 |
Insulation grade |
F |
Duty cycle |
60% |
Efficiency |
85% |
Air pressure (CUT) |
0.5 MPa |
Gas flow (TIG) |
2-5 L/min |
Gas flow (CUT) |
100 L/min |
Cutting thickness (CUT) |
1-10 mm |
Weight |
12.4 kg |
Dimension (mm) |
575*320*455 |
* BUY WITH CONFIDENCE.
* QUALITY MACHINES MANUFACTURED BY RONGYI.
* FULL SERVICE AND PARTS BACK UP.
* 12 MONTHS WARRANTY.
The data in the above table is only for reference. Please subject to the nameplate
on the device.
