Features of Shanghai Rongyi IGBT Inverter AC/DC Pulse TIG/MMA high frequency welding machine WSME315 :
1. IGBT inverter technology and precision constant current feedback control technology, soft switch, high working efficiency;
2. Wide working voltage range, strong adaptability to electricity power grid fluctuation, excellent arc striking performance;
3. Thermostatic protection, over-voltage protection, over-current protection, under-voltage protection,;
4. Applicable for TIG and MMA welder;
5. Suitable for metal sheets: stainless steel, carbon steel, alloy steel, titanium, etc;
6. Complete accessories: welding torch, welding cable, earth clamp, welding holder.
Parameters of Shanghai Rongyi IGBT Inverter AC/DC Pulse TIG/MMA high frequency welding machine WSME315 :
|
Model Spec. |
WSME315 |
Power supply voltage |
3-ph AC 380±10% V / 50~60 Hz |
Power supply capacity |
9.3 kVA |
Rated input current |
14.4 A |
No-load voltage |
62 V |
Duty cycle |
60% |
Output current range |
5-315 A |
Pulse frequency |
0.5-12 Hz |
Up-slope time |
0-10 s |
Down-slope time |
0-10 s |
pre-flow time |
1 s |
Post-flow time |
0-30 s |
Weight |
40 kg |
Dimensions (mm) |
575*325*585 |
* BUY WITH CONFIDENCE.
* QUALITY MACHINES MANUFACTURED BY RONGYI.
* FULL SERVICE AND PARTS BACK UP.
* 12 MONTHS WARRANTY.
The data in the above table is only for reference. Please subject to the nameplate on the device.
