ARC140 MOSFET INVERTER DC ARC Welding Tools

Name: ARC140 MOSFET INVERTER DC ARC Welding Tools
Brand: RONGYI
Availability: InStock

FOB Price

USD $1 - $200 / Set

1 Set(Min.Order)

Supply Ability 8000 Set / Sets per Month
Port Shanghai
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Shanghai, China
Brand Name	RONGYI	Model Number	ARC140
Arc Current	140A	Pulse Frequency	10-100kHz
Pilot Arc Current	5A	Rated Duty Cycle	60%
Motor Type	DC Motor	Dimensions	385155295 mm
Usage	WELD	Voltage	1-Ph AC 220±10% V / 50~60Hz
Power(W)	3.5 kVA	Certification	CE, CCC, CE,CCC
Warranty	1 Year

Product Description

Specifications

MOSFET inverter
precision constant current feedback control and technology,
soft switch
INVERTER ARC Welding Tools

The features of INVERTER ARC Welding Tools ARC140:

1. MOSFET inverter and precision constant current feedback control and technology, soft switch;

2. Wide working voltage range, strong adaptability to electricity power grid, high ability of interference resistance, stable welding current and steady arc;

3. Intensive arc, high welding speed, excellent welding performance, deep welding pool, less spatter, continuous current regulation, safety and reliable for operation;

4. Compact structure, portable, energy saving, easy for maintenance;

5. Applicable to various acid and basic welding electrodes;

6. Suitable for stainless steel, copper, cast iron, carbon steel, alloy metal, etc. ;

7. Complete accessories: welding torch, welding cable, earth clamp, welding holder.

The parameters of INVERTER ARC Welding Tools ARC140:

Model Spec.	ARC140
Power supply voltage	1-Ph AC 220±10% V / 50~60Hz
Power supply capacity	3.5 kVA
No-load voltage	56 V
Out put current range	5-140 A
Power output voltage	26.4 V
No-load loss(W)	30
Duty cycle	60%
Cosφ (η)	0.73
Protection	IP 21S
Insulation grade	F
Diameter of rod	1.6-3.2 mm
Net Weight	8.0 kg
Dimension (mm)	385155295

* BUY WITH CONFIDENCE.

* QUALITY MACHINES MANUFACTURED BY RONGYI.

* FULL SERVICE AND PARTS BACK UP.

* 12 MONTHS WARRANTY.

The data in the above table is only for reference. Please subject to the nameplate on the device.

RONGYI Buildings

Our Certifications

Products and Package

Some PCB s

Accessories
