Electric Rotary Actuator

Name: Electric Rotary Actuator
Brand: GINICE CO.,LTD
SKU: 107086479

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Gyeonggi-do, South Korea

Brand Name:

GINICE CO.,LTD

Model Number:

GQ-010,016,024,035,050,080,110,200,300

Ginice Co.,ltd

Payment & Shipping

Payment Methods:

Port of Shipment:

Incheon Busan

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Gyeonggi-do, South Korea

Brand Name GINICE CO.,LTD

Model Number GQ-010,016,024,035,050,080,110,200,300

Enclosure	Weather proof enclosure IP67(IP68 optional)
Power supply	110/220V AC 1 Phase 50/60Hz, 380/440V AC 3 Phase 50/60Hz, ±10%
Control power supply	110/220V AC 1 Phase 50/60Hz, ±10%
Dury cycle(on-off)	S2, 100% Max 30Min
Duty cycle(modulating)	S4, 70% Max 300~1,600 start / hour
Motor	Induction motor (Reversible motor)
Limit switches	Open / close, SPDT, 250V AC 16A rating
Additional limit switches	Open / close, SPDT, 250V AC 16A rating (Except for GQ-010)
Torque switches	Open / close, SPDT, 250V AC 16A rating (Except for GQ-010)
Stall protection/operating temp.	Built-on thermal protection, open 150°C±5°C / close 97°C ±15°C
Travel angle	90°± 5°(0 ~100°)
Manual override	Declutching mechanism
Indicator	Continuous mechanical indicator with arrow
Self locking	Provided by double worm gearing
Mechanical stopper	2 each external adjustable screws
Space heater	10W (110/220V AC) anti-condensation
Cable entries	Three PF ¾″tap
Lubrication	Grease Moly (EP type)
Terminal block	Spring loaded lever push type
Materials	Aluminum alloy, Steel, Al bronze, Polycarbonate
Ambient temp.	-20° ~+70°C (expect option electronic board)
Ambient humidity	90% RH Max. (non-condensing)
Anti vibration	X, Y, Z 9g, 0.2~34Hz, 30min.
