motion sensor lamp AC 160W led high bay with 1-10v dimmable model
Name |
microware motion sensor AC LED High Bay Light 1-10v dimmable |
Rated power |
160W±5w @220~240VAC input |
Input voltage |
AC200~265V 50/60HZ |
Model Number |
SMD300-160XW-P120 -MW |
Driver |
AC integrated Driver |
Protection |
With OTP, OVP, OCP and up to 4KV Surge protection |
Led chip brand |
Nichia SMD3030 (757) |
Dimming |
Microware motion sensor 1~10V dimmable |
CRI |
>80 |
LED Luminus |
15000lm diffused cover;16000lm transparent cover |
Power factor |
>0.97 |
Beam angle |
120 / 60 (with reflector) degree |
Color temp. |
3000K-4000K-6000K |
Base Type |
Hook / E40 |
Material |
Aluminum + PC |
Lamp weight |
2.5kgs |
Packing weight |
3.5kgs |
Product size |
292*404(E40) / 292*422mm(HOOK) |
Packing size |
360*360*485mm |
Certification |
CE RoHS SAA |
Product picture:
Microware motion sensor picture:
Microware motion sensor profile and size(mm):
Microware mition sensor specific application:
Detection area
Detection area can be reduced by selecting the combination on the DIP switches to fit precisely each application
Hold time
Refers to the time period the lamp remains at 100% illumination after no motion detected.
Stand-by period
Refers to the time period the lamp remains at a low light level before it completely switches off in the long absence of people. When set to Disable mode, the low light is maintained untill motion is detected.
Stand-by dimming level
The low light level you would like to have after the hold time in the long absence of people.
Daylight sensor
The sensor can be set to only allow the lamp to illuminate below a defined ambient brightness threshold. When set to Disable mode, the daylight sensor will switch on the lamp when motion is detected regardless of ambient light level.
50lux, 30lux: twilight operation, 10lux, 5lux: darkness operation only.
Note that daylight sensor is active only when lamp to tally switches off.
