Help CenterPCB-25001(D) Powder Coating Paint Booth
Related Products
-
PCB-28001 Powder Coating BoothUS$ 5,000 - 10,000MOQ: 1 Set -
PCB-25001(D) Powder Coating SystemUS$ 7,000 - 10,000MOQ: 1 Set
-
PCB-25001(D) Powder Coating SystemUS$ 7,000 - 10,000MOQ: 1 Set
-
PCB-24001 Powder Coating SystemUS$ 2,000 - 6,000MOQ: 1 Set
-
PCB-28001 Powder Coating SystemUS$ 2,000 - 6,000MOQ: 1 Set
powder coating booth
Type |
Powder coating booth |
||
Brand |
King |
||
Model no. |
PCB-25001(D) |
||
Production Capacity |
100 SETS PER MONTH |
||
Voltage |
AS REQUIRED |
||
Power |
AS REQUIRED |
||
Place of Origin |
CHINA |
||
Dimension |
2500(W)*2500mm(D)*2200mm(H) |
||
Material |
Made of cold-plates, powder coated. |
||
Powder recovery system |
Dust filter cartridge |
6pcs |
|
Solenoid valve |
6pcs |
||
Circulation system |
1 set of centrifugal blower, motor 7.5KW,air flow 5500~10000m³/h |
||
Lighting system |
6 SETS |
||
Pulse Programmed control system |
1 set |
||
Weight |
1600KGS |
||
Warranty |
12 MONTHS |
||
1. we are factory manufacturer;
2. the company got ISO9001 certificate;
3. the products get CE certificate;
4. the burner both are italy RIELLO burner;
5. over 20 years experience;
6. have export experience;
7. we have stock for the goods;
8. the gun have 3-year warranty period.
Advantages for the KING powder coating spray booth
1. Simple to Install
a. Bolted construction makes the booth structure easy to arrange and assemble.
b. All power and interlock connections are made to one location for fast, simple installation.
c. Optional preassembled booth structure can save installation time.
2. Easy to Use
a. As a building material, PolyVinyl Chloride is durable, and easy to assemble.
b. PolyVinyl Chloride is an extremely durable plastic material that resists abrasion and scratching.
c. The hard, slick surface of the KING Booth stays smooth, clear and easy to clean.
d. The proven vertically mounted filters ensure easy access and reduced maintenance time over other designs.
e. Side-draft cartridge modules are interchangeable for simple and easy color changes.
f. The mobile cartridge collector assembly features an automatic locking device to ensure a tight fit. Minimal effort is required by the operator to change collectors.
g. When a fast color change is needed, two or more KING Series booths can be installed in a roll on/off configuration.
h. Collector opening is at floor level for easy removal of powder from the booth floor and for transfer back to the reclaim assembly.
3. Efficient Design
a. Location of automatic gun slots, manual openings, the collector module and the aerodynamic design of the vestibules all contribute to maximize first pass powder transfer efficiency.
b. Clear PolyVinyl Chloride panels provide the best possible lighting for product application.
c. Complete visibility of spray operation is available at all times, allowing visual monitoring of both manual and automatic gun performance.
d. Filter performance is monitored to maintain peak operating efficiency.
e. Cabin structures are arranged to meet specific application needs with our unique combination of clear and stainless steel structure, or an optional all stainless configuration.
f. Compact floor space design of collection equipment saves on plant floor space.
g. All KING Series booth bases are designed to integrate into most standard systems without conveyor elevation changes.
h. Each cabin structure incorporates air flow vestibules in each automatic gun slot, channeling the airflow around the gun and ensuring containment of oversprayed powder.
i. Side-draft collection provides uniform airflow while allowing the operator to visually inspect the level of powder in the bottom of the collector.
j. Unique to KING equipments, direct drive fan provides uniform air volume performance over the full life of the cartridges.
k. Highly efficient fan system helps booth rank as quietest on the market.
l. Low pressure, high volume back-pulse reduces noise and improves cartridge life.
4. Outstanding Performance
a. Cartridge filter design maximizes both life and powder recovery performance of the filters, providing maximum filtration at the lowest possible pressure drop.
b. Uniform disbursement of recovery air recycled through highly efficient safety filters.
c. PolyVinyl Chloride material reduces the amount of powder build-up on booth walls, allowing more powder to be attracted to the part, thus minimizing clean up.
d. Aerodynamic side-draft design creates a superior application zone for repeatable performance.
e. Open-face collector promotes uniform air flow at lower velocity contributing to more consistent application performance.
f. Efficient design provides greater than 95% material utilization.
Application: used for the powder coating and line, plant
Shipping: can ship to any port from QINGDAO PORT by sea.
Payment methods: escrow, T/T, L/C
Packing: proper packing suitable for container loading
we supply following equipment:
1. liquid paint coating equipment
1.1 Car spray&baking room system
1.2 Bus spray&baking room system
1.3 Furnitue spray&baking room system
1.4 Industrial painting&baking room system
1.5 High temperature painting&baking room system
1.6 Customized spray&bake booth. Offer car spray baking booth accossories
2. electrostatic powder coating equipment
2.1 electrostatic powder coating spray gun machine(manual/auto)
2.2 electrostatic powder coating application spray booth/cabin(manual/auto)
2.3 electrostatic powder coating curing oven/furnace(batch type/bridge type/tunnel type)
2.4 electrostatic powder coating conveyor line(manual/semi-auto/fully auto)
2.5 electrostatic powder coating sieve machine
2.6 electrostatic powder coating reciprocating machine
2.7 electrostatic powder coating plant
We have more than 20year experiences on powder coating equipments, which got CE certification and ISO9001 quality certification.
We are a typical Chinese supplier and specialized in the research, development and production of powder coating equipments, such as powder coating gun, reciprocator, powder coating booth, powder coating oven, semiauto powder coating line and full auto powder caoting line and so on.
We insist in offering superior quality products and efficient service.
If you are interested in any of our products or would like to discuss a custom order, please feel free to contact us. We are looking forward to forming successful business relationships with new clients around the world in the near future.
If have any problems or need any help, please click the "SEND" or "CONTACT" button!
1.When did your company commence its business?
OUR COMPANY FOUNDED AT THE YEAR OF 2001.
2.Where is your Company situated?
KING COATING EQUIPMENTS FOR LIQUID PAINTING EQUIPMENTS LOCATED IN BINZHOU CITY, SHANDONG PROVINCE.
KING COATING EQUIPMENTS FOR POWDER COATING EQUIPMENTS LOCATED IN QINGDAO CITY, SHANDONG PROVINCE.
IF YOU WANT TO VISIT US, YOU COULD TAKE PLANE TO QINGDAO AIRPORT OR JINAN AIRPORT.
3.How can I pay you from abroad?
YOU COULD TRANSFER THE PAYMENT VIA T/T OR LC, WE COULD PROVIDE YOU THE BANK DETAILS.
4.How do you ship the goods?
GENERALLY, WE SHIP THE GOODS BY SEA. AND IF YOU HAVE SPECIAL REQUIREMENTS OR NEED DOOR-TO-DOOR SERVICE, PLEASE KINDLY TELL US THE DETAILED ADRESS TO HELP YOU CALCULATE THE ACCURATE COST.
5.How do you provide after sales support?
WE PROVIDE VERY ACTIVE SUPPORT BY TELEPHONE & INTERNET& EMAILS TOO. IF NECESSARY, WE ALSO COULD SEND TECHNICALS THERE TO HELP THE CUTOMERS SOLVE THE PROBLEMS. WE ARE CONSTANTLY LOOKING FOR NEW WAYS TO IMPROVE THE COMMUNICATION AND CLIENT RELATIONS.
6.How is the booth shipped and how long will it take to get once I order it?
MANY MODELS ARE IN STOCK AND COULD SHIP UPON RECEIPT OF THE PAYMENT FOR THE ORDER. OTHER MODELS THAT ARE NOT IN STOCK COULD TAKE FROM 1 TO 6 WEEKS TO SHIP DEPENDING ON THE MODEL AND IF IT HAS TO BE DRAWN BY THE ENGINEERING DEPARTMENT BEFORE IT CAN BE PRODUCED. ONCE THE BOOTH IS SHIPPED CIA COMMON FEIGHT CARRIER, THE ARRIVAL TIME DEPENDS ON WHERE YOU ARE FROM.
