Water-cooled Industrial Chiller With Imported Conpressor,pump MCA-10

Name: Water-cooled Industrial Chiller With Imported Conpressor,pump MCA-10
Brand: JIAYIN
SKU: 107060643
Availability: InStock

US$ 2,000 - 10,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

JIAYIN

Model Number:

MCW-10

Guangzhou Jiayin Machinery Pte., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen/guangzhou

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name JIAYIN

Model Number MCW-10

Specifications

Industrial water cooled Chiller:
1.different size of air & water cooled chiller
2.water cooled chiller with Imported compres

Industrial water cooled Chiller:
1.different size of air & water cooled chiller
2.water cooled chiller with Imported compresor

Industial Water cooled Chiller:

Website:

Features:

1,Designed with imported compressor and water pump for ultra-powerful refrigeration,with prolonged service life;

2,High-efficiency evaporator and condenser realizing rapid thermal transfer;

3,Open-type stainless steel water tank,easy and fast to clean and maintain;

4,Double-compressor design to save energy and power;

5,Well-structured safety protection and trouble indication system;

6,Microcomputer touch-type control,accurate temperature control and simple operation

Safety protection system:

No tatal power circuit breaker

Compressor overload protection

Circulating pump overload protection

Anti-phase and open phase protection

High&Low pressure protection for refrigerant

Freezing protectionTrouble indicator and abnormality buzzer alarm.

Remark:Water cooled Water Chiller needs to work with Cooling Tower

Specifications of water chiller(water-cooled&air-cooled):

Model	MCW-5	MCW-10	MCW-15	MCW-20	MCW-30		MCW-40
Refrigerating Capacity(Kcal/h)	12900	26230	38700	52460	79120		104920
Power of Compressor(HP)	5	10	15	20	30		40
Flow of cooling Water(L/min)	56	114	169	220	337		532
Pipe dia. of Cooling water(mm)	40	40	50	50	65		80
Flow of chilled water(L/min)	45	93	137	178	274		427
Pipe dia. of chilled water(mm)	13 with 5 groups	40	50	50	65		80
Power of chilled water pump(HP)	1	2	3	3	5		5
Overall dimensions(cm)	90×46×91	150×70×130	170×75×140	92×46×144	190×80×144		200×90×150
Weight(kg)	160	410	480	540	680	810
Refrigerant	R22
Input power	3-phase 380V 50HZ;3-phase 220V 60HZ
Restrictor	Expansion valve
Condenser	Shell&tube condenser
Evaporator	Shell&tube evaporator
