Specifications
Name:zinc nutSize:M3-M64
Surface:plain,zp,balck,HDG
Package:bulk and box
zinc hex nut
1) Different kinds of nuts available ,M3 to M30 to be mae by cold forming, M33 and
up to be made by hot-forging.
2) Different finish, such as bright, zinc plated, yellow zinc plated
3) Can be made as low carbon steel and high tensile
4) Mainly used for indoor and outdoor construction field
5) Special anchors can be supplied according to customers' drawings or samples
| Nominal | Pitch | m | S | Weight | ||
| Diameter | 1000pcs | |||||
| D | P | max | min | max | min | Kg |
| M1 | 0.25 | 0.8 | 0.55 | 2.5 | 2.4 | 0.03 |
| M2 | 0.4 | 1.6 | 1.35 | 4 | 3.82 | 0.142 |
| M3 | 0.5 | 2.4 | 2.15 | 5.5 | 5.32 | 0.384 |
| M4 | 0.7 | 3.2 | 2.9 | 7 | 6.78 | 0.81 |
| M5 | 0.8 | 4 | 3.7 | 8 | 7.78 | 1.23 |
| M6 | 1 | 5 | 4.7 | 10 | 9.78 | 2.5 |
| M7 | 1 | 5.5 | 5.2 | 11 | 10.73 | 3.12 |
| M8 | 1/1.25 | 6.5 | 6.14 | 13 | 12.73 | 5.2 |
| M10 | 1/1.25/1.5 | 8 | 7.64 | 17 | 16.73 | 11.6 |
| M12 | 1.25/1.5/1.75 | 10 | 9.64 | 19 | 18.67 | 17.3 |
| M14 | 1.5/2 | 11 | 10.3 | 22 | 21.67 | 25 |
| M16 | 1.5/2 | 13 | 12.3 | 24 | 23.67 | 33.3 |
| M18 | 1.5/2/2.5 | 15 | 14.3 | 27 | 26.16 | 49.4 |
| M20 | 1.5/2/2.5 | 16 | 14.9 | 30 | 29.16 | 64.4 |
| M22 | 1.5/2/2.5 | 18 | 16.9 | 32 | 31 | 79 |
| M24 | 2/3 | 19 | 17.7 | 36 | 35 | 110 |
| M27 | 2/3 | 22 | 20.7 | 41 | 40 | 165 |
| M30 | 2/3.5 | 24 | 22.7 | 46 | 45 | 223 |
| M33 | 2/3.5 | 26 | 24.7 | 50 | 49 | 288 |
| M36 | 3/4 | 29 | 27.4 | 55 | 53.8 | 393 |
| Product | Carbon steel black zinc plated hex nut | ||||
| Material | Carbon steel | ||||
| Finish | zinc plated | ||||
| Size | 1-1/8inch-1-1/2 inch | ||||
| Thickness | 1.03inch-1.276inch | ||||
| Standard | ANSI B 18.2.2 | ||||
| Factory | NingBo | ||||
Company Information
Used for mounting of pipes to the walls ( vertical / horizontal ) , ceilings and floors
For Suspending Stationary Non-Insulated Copper Tubing Lines
Being fasteners for pipe lines such as heating, sanitary and waste water pipes;to walls, ceilings and floors.
Side screws are protected against loss during assemble with the help of plastic washers
