china 12 pole electrical feed through low voltage screw plastic terminal block connector
- 0 per Month
- Custom-fabricated battery bus bars electrically inter-connect a range of battery cells
- OEM ODM focused rigid copper busbar for yacht
- Ballast-to-luminaire disconnects, Push-In Type
- Push Wire Cable Connector Terminal Block For LED Light
- Compact Splicing Connector For LED Light
- Electrical Splitter Universal Cable Connector For LED Light
Product Details
Place of Origin: | Zhejiang, China | Brand Name: | JESUO | Model Number: | 30A |
Number of Contacts: | 11 - 20 | Conductor Size: | 21 - 30 AWG | Type: | Screw |
Product Description
Product Description
H series 12 pole terminal blocks are suitable for continuity or branching-off connectors between electric conductors.
1.Name: china 12 pole electrical feed through low voltage screw plastic terminal block connector
2.Insert: brass
3.Plastic: PE, PP or PA
4.Max. Operating temperature: -5~+85 for PE
5.Standard:EN60998-1 EN60998-2-1
6.Color :Natural, Black, White
Feed through terminal block sizes
Item No | Rated current(A) | Section size(mm2) | Dimension (mm) | |||||
L(mm) | W(mm) | H(mm) | A(mm) | B(mm) | Ød(mm) | |||
A-3 | 3 | 2.5/4 | 92 | 15.5 | 12.7 | 5.5 | 8 | 3 |
A-6 | 6 | 6 | 119 | 17.3 | 13.9 | 6.5 | 8.2 | 3.3 |
A-10 | 10 | 10 | 131 | 20.85 | 16.4 | 7.25 | 11.2 | 3.71 |
A-15 | 15 | 12 | 135 | 22.65 | 18.25 | 8.25 | 11.5 | 4.2 |
A-20 | 20 | 14 | 141.6 | 22.65 | 18.4 | 8.5 | 12.2 | 4.5 |
A-30 | 30 | 16 | 165 | 24.1 | 21.1 | 9.5 | 14.1 | 5.5 |
A-60 | 60 | 25 | 190 | 30.8 | 25.2 | 11.15 | 16.5 | 6.3 |
A-80 | 80 | 30 | 201 | 36 | 22.65 | 12.1 | 18.15 | 6.9 |
A-100 | 100 | 35 | 228 | 38 | 33 | 13.8 | 19.4 | 7.4 |
A-150 | 150 | 40 | 261 | 44 | 33 | 21.2 | 22 | 8.3 |
Advantages
Complete products: | Terminal block,insulate terminals etc 36 kinds of wiring accessories series |
Quality assurance: | Strict quality control before shipment |
High efficiency: | Handling customer questions within 24 hours |
Increase customer utility: | Personal tracking, 5 to 10 days shipment after received payment |
