PVC Pin Shaped Pre-insulated Terminals
US$ 0.72 - 3.3
MOQ: 1000 Bags
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
JESUO
Model Number:
PTV1.25-9~PTV5.5-13
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Tube Pre-insulated TerminalUS$ 2.3 - 13.7MOQ: 100 Bags -
TE Insulated Terminals Insulated Twin Cord End Terminals Copper Tube High Quality Low PriceUS$ 0.41 - 2.5MOQ: 100 Bags
-
High Quality SC Tinned Copper Cable LugsUS$ 0.03 - 9.3MOQ: 10000 Pieces
-
Cable Lugs and Copper Cable Terminals LugsUS$ 0.03 - 9.3MOQ: 1000 Pieces
-
EN Copper Material Tube Naked Terminal ,Cable TerminalUS$ 0.01 - 1MOQ: 100 Bags
Place of Origin
Zhejiang, China
Brand Name
JESUO
Model Number
PTV1.25-9~PTV5.5-13
Type
Crimp Terminal
Product Description
The Kind of pre-insulated terminals we offer are: Fork Shape pre-insulated terminals , Ring Shape pre-insulated terminals , Needle Shape pre-insulated terminals , Pre-insulation Peggy Back Terminal, Plate Shape Pre-insulation Terminal.
1.Material:copper and PVC
2.Size of cable: 0.5~6mm2
3.Max. Current: 19A, 27A, 48A
4.Various wire range
5.Made by high purity copper
Schematic diagram
Insulated Terminals Size
| Size of cable: 0.5~1.5mm2 (A.W.G 22~16) Max. Current=19A | ||||||
| Item No . | Dimension (mm) | Color | ||||
| L | FØ | E | DØ | dØ | ||
| PTV 1.25-9 | 19 | 1.9 | 10 | 4.3 | 1.5 | Red |
| PTV 1.25-10 | 20 | |||||
| PTV 1.25-12 | 22 | |||||
| PTV 1.25-13 | 23 | |||||
| Size of cable: 1.5~2.5mm (A.W.G 16~14) Max. Current=27A | ||||||
| Item No . | Dimension (mm) | Color | ||||
| L | FØ | E | DØ | dØ | ||
| PTV 2-9 | 19 | 1.9 | 10 | 4.9 | 2.4 | Blue |
| PTV 2-10 | 20 | |||||
| PTV 2-12 | 22 | |||||
| PTV 2-13 | 23 | |||||
| Size of cable: 4~6mm2 (A.W.G 12~10) Max. Current=48A | ||||||
| Item No . | Dimension (mm) | Color | ||||
| L | FØ | E | DØ | dØ | ||
| PTV 5.5-13 | 25.5 | 2.8 | 12.5 | 6.7 | 3.2 | Yellow |
Advantages
| Complete products: | Insulate terminals,terminal block etc 36 kinds of wiring accessories series |
| Quality assurance: | Strict quality control before shipment |
| High efficiency: | Handling customer questions within 24 hours |
| Increase customer utility: | Personal tracking, 3 to 10 days shipment after received payment |
