Cement Pipe Making Machine in Zambia
- 2 Set / Sets per Month
- Qingdao port
- T/T
- CNC router for stone processing engraving machine
- Glass polishing machine JMB95A
- Aluminum Profile Bending Machine/Arc Bending Machine for Aluminum
- Automatic aluminum window corner connector cutting machine
- aluminum door and window frame cutting machine aluminum windows and doors machine
- Upvc Window Door Machine Four Head Welding Machine for PVC welding Window Machine
Product Details
Condition: | New | Type: | Pipe Production Line | Pipe Material: | Other, casting steel, concrete |
Application: | Other, Energy Supply Pipe, Drain Pipe | Production Capacity: | 10-15M/Min | Place of Origin: | Shandong, China |
Brand Name: | HY | Power(W): | 15KW | Dimension(L*W*H): | 3500*1500*1300mm |
Weight: | 15T | Certification: | ISO9001 | Warranty: | 1 year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
Made of casting steel,Pipe machines produce various concrete drainage pipes with centrifuge or hanging roller pipe machine.
1. Overview of Suspension Roller type Cement Pipe Machine
Suspension roller type cement pipe machine is a kind of perfect machine and equipment to produce reinforced cement pipes and Pre-stressed cement pipe. This machine is capable to make pipes with diameter from 300-2000mm and with length from2-4meters. We can design many kinds of the pipe joint, including flush joint, socket & spigot joint And all the cement pipes are widely used in administrative drainage, agricultural field irrigation, road culvert and deep water well.
2. Working Principle of Suspension Roller type Cement Pipe Machine
This machine uses the Roller to support the cement pipe machine, and produce the roller force to concrete in the mould. When the roller rotate at a high speed, the concrete in the mould will spread in the inner wall of the pipe mould and form a cement pipe with the centrifugal force, and when the mould with the inner concrete pass on the roller, the concrete between the mould and the roller will be compacted solid to form a pipe.
3. Character of Suspension Roller type Cement Pipe Machine
3.1 Short production Cycle: because of the good effect of the roller to compact the concrete, every pipe just need 3-5 minutes with high speed roller rotation.
3.2 This pipe machine uses the dry cast material, there will no waste cement mud, then it won't pollute the environment.
3.3 During the production, the noise is low, it is about 80-90 DB.
3.4 The cement pipes are with high pressure load and with high production efficiency.
4.Technical Parameter of Suspension Roller type Cement Pipe Machine
XG 200-600 | XG 800-1200 | XG 1000-1500 | XG 4M | |
Diameter | 200-600mm | 800-1200mm | 1000-1500mm | 300-2000mm |
Length | 2000mm | 2000mm | 2000mm | 1000-4000mm |
power of motor | 15kw | 45kw | 90kw | 110kw |
Capacity | 10-15pc/h | 8-12pc/h | 6-10pc/h | 6-8 pc/h |
Labor demand without feeding machine | 4-5 | 4-5 | 4-5 | 4-5 |
labor demand with feeding machine | 3-4 | 3-4 | 3-4 | 3-4 |
Joint | Plain,socket and spigot,male and female | plain,socket and spigot ,male and female | plain,socket and spigot ,tongue and groove | plain,socket and spigot,tongue and groove |
Packaging Details: wooden box and other packing materials as per kinds of machines or as customer request
Delivery Detail: Within one month after received your deposit.
1.Complete production line supporting machines and all necessary accessories with high performance and good quality;
2. Free Service of plant structure design and layout plan drawings and other necessary construction drawings and guidance of construction work,office, warehouse etc and related drawings according to customers’ requirements.
3.Installation and commissioning of all production machines as well as the workers training.
Shandong Haiyu Industry Co., Ltdis a leading manufacturer producing completed sets of pre-stressed and reinforced spun concrete electric pole production lines,concrete pipe production lines and concrete pile production lines with passing ISO9001:2008 quality management system certificate.Recent years, adopting new technology to improve main machines to adapt to latest market demand and years of experience in manufacturing PSC and RCC concrete pole machines and concrete drainage and well pipe machines, Our company has not only sold our products very well in Asian countries(Cambodia,Laos,Vietnam,Afghanistan etc.),African countries(Kenyan, Ethiopia,Ghana,Sudan etc) and other countries but also developed and manufactured various kinds of advanced concrete products equipments and molds and building materials machinery equipments. Warmly and Sincerely Welcome You To Visit Our Company !
1. Specifications of Cement Pipe :Length, Diamete and joint ways.
2. Type of concrete pipe joint : Spigot and bell , Tongue and groove ,plain joint .
3. Daily or Annual Productivity.
