Server based computing With 3 USB Wireless Thin Client Mini PC For All Windows/Linux

Specifications

1.3 USB port, WIFI optional
2.Support Unlimited Users
3.Energy-efficient (under 5 watts per user)
4.up to 24 bit color minipc

Overview



Thin Client pc station is based upon multi user computing technology allowing all users to use software’s and hardware capacity of a single HOST SERVER and its peripherals independently and synchronously. Remember using thin clients helps in reducing costs in maintenance and up gradation of a CPU too.



Thin Client PC Station Terminal N630 has the most user-friendly and smart-looking design. The creative designed 2D graphics processor supports Microsoft Windows GDI GUI acceleration. Excellent office work and also perfect in entertainment.



Main benefit of PC Stations:



1.       Share your one computer with 20, 30 or even 100 more users

2.       More than 98% Computing cost saving:

l           Hardware: Most PC Station price between 25 to 50 USD, only around 10% of normal fat computer cost

l           Software: All station users share the same software with HOST, so only need to buy 1 suit software for HOST pc, if you share 10 users with one host, you will save 90% software cost, share 20 or 30 or even more users per host, you will save much more than 90%.

l           Energy cost: Station only cost less than 5W, compare to the 150W energy consumption, you can see how much it help you to save.

3.       Many other benefit like saving maintenance cost, easy to use and smart design takes no paces of your office, and so on...



Technical advantage of WinCE PC Station:



1. Thin Client mode

With RDP technology, you can set up thin client model, the desk of PC Station use all the resources of the HOST PC, and run remote desktop. It works just like a full typical desktop computer



2. Mini PC mode

WinCE PC Station can work as a stand-alone mini computer. You can surf internet, enjoy cloud computing, run simplify Office software and even download data to your USB flash memory or other moving HDD





Thin Client PC Station Terminal N630HW Specification:



Hardware
CPU	Onboard CPU CLG7700 800MHz(ARM11)
Memory	Onboard 128 MB RAM
Storage	Onboard 128 MB Flash
System	Buildin Windows CE 6.0, support all windows pro and linux HOST
Weight	Terminal: 250g Shipping Weight: 550g
Power Supply	Input: 100-250 VAC, 50-60 Hz; Output: 5 VDC, 1 A Nominal consumption: 5 Watts
Front LED Indicators	Green LED located on front of access device
I/O	3* USB 2.0, MIC in and speaker out, RJ 45 Lan, VGA, 5V DC in, Switch on/off
Internet function
Connection to Host PC	Unlimited distance via 100 Mb/s switched Ethernet connection
Video Resolution	640*480, 800*600, 1024*768 (at 60or 70 Hz refresh rate) and 1280*1024(63Hz), 1440*900(60Hz). All feature up to 24-bit color support
Language	Local system English, support multipule language after connect to HOST
Audio	Stereo output and Microphone Input
Internal HW	All solid-state design, no moving parts, no fans, no local user storage Windows CE intergraded RDP protocols
Reliability (MTBF)	>>100,000 hours (calculated using Bellcore Issue 6 TR-332, Case 2, Part I at 40°C)
HW Security	No local user storage
Terminal Service Software
Max # Users Per PC	No limitation when using a server host OS (i.e. Windows Server 2003) max 25 users when using a desktop OS (i.e. Windows XP)
User Software	PC Station terminal services software
Supported Operating Systems	All Windows OS Professional, such as XP, 2003, 2008, VISTA, WIN7…, all Linux version with RDP protocol, such as Ubuntu10.04
System Requirements and Options
Kit Contents	EGLOBAL PC STATIONS Kit includes access terminal, power supply, software installation & user’s guide, other peripherals like monitor or KB and mouse are NOT included and must be purchased separately.

Recommended host configuration according to ures number

User No.	1-4	5-10	11-20	21-30	31-50	51-70	71-100
Host PC CPU&Memory	>2.4 GHz P4  with 512MB	>3.0 GHz P4  with 2GB	Intel P4 3.2GHz with 3GB	XEON3.2CHz or XEON2.8GHZ DUAL with 4GB	XEON E5506*2 4G*4 DDR3/1333 ECC REG	XEON E5506*2 4G*6 DDR3/1333 ECC REG	XEON E7520*2 16G*4 DDR3/1333 ECC REG
