Specifications
1. HDMI 1080P, Support PXE2. Full I/O support
3. Pre-installed all windows/linux
4. Smart design and Powerful Specification
Specifications
1. Full Aluminium Alloy
2. 1080P, WIFI, DDR2 RAM
3. Pre-installed all windows/linux
4. Intel Atom N270 Core 1.6GHz
Overview:
1. Hard decode Blue High-Definition, Wi-Fi antenna
2. High-grade and elegant standing outside looking, full aluminum alloy, VGA, RJ45 Lan... full I/O make sure all your application supported
4. Low-Energy, power supply only 12V 6A, when running, power consumption less than 20W
5. Supper strong performance, with Intel Atom N270 1.6GHz, 1-2GB memory and new technical Solid State Disk
6. Top grade quality, all material comes from qualified trustable factory and big brand
Top Advantage:
1. Pure high grade Alloy computer case
2. Smart design and Powerful Specification
3. Low Consumption long time stable working
4. HDMI 1080P, Support PXE
5. Full I/O support
Package details:
1. Include Mini PC, Driver CD, Power Adapter
2. Item Size: 20.5*14*4cm
3. Color Package size: 33*8*26.5cm; Shipping carton per unit: 36.5*10.7*29cm
Support OS: Windows XP, XPE, Win7, 2008& est., Linux
General | |
CPU |
Intel N270 Core 1.6GHz main Frequency, 533MHz External Frequency, 512 MHz Cache Consumption 4W, fan less, whole computer consumption less than 20W |
System |
Pre-installed Linux Ubuntu system and all windows |
Memory |
DDR2 SO-DIMM 1GB, Max 2GB optional |
Lan |
1 * RJ45 RTL8111DL 10~100~1000M self-adaption Lan card |
Graphics card |
Intel GMA950, 128M video memory standard, max 256M |
Hard disk |
SATA SSD 8GB, notebook HDD 160G, 320G,500G optional |
Performance | |
CPU port |
BGA Packaging, Onboard CPU |
Chipset |
Intel® 945GSE Express Chipset |
BIOS |
AMI BIOS, ACPI supported |
Memory |
1* SO-DDR2 SDRAM slot, max 2G DDR SDRAM PC533/667/800 DDR SDRAM |
Lan |
RTL 8111DL 10/100/1000 Base T LAN, support diskless RPL or PXE guiding |
Audio Card |
ALC662 chip, 6 channel sound card |
I/O |
FINTEK71862FG chip, support 12V and 5V power supply, GPIO; 2 SATA (Serial II ATA) support 3Gb/s; 150M Wi-Fi optional 6*USB (4 front 2 rear port), VGA CRT, 1*RJ-45, 4 *USB ports |
Power supply |
DC 12V |
Dimension |
Product dimension: 205*140*40mm Color Package: 330*265*80mm |
Weight |
NW: 1kg Shipping GW: 2 KG |
