Intel Celeron Quad Core Mini pc N2920 1.86Ghz Max 2.0Ghz Industrial Computer Fanless Desktop Window s XBMC

Intel Celeron Quad Core Mini pc N2920 1.86Ghz Max 2.0Ghz Industrial Computer Fanless Desktop Window s XBMC thumbnail-1
Intel Celeron Quad Core Mini pc N2920 1.86Ghz Max 2.0Ghz Industrial Computer Fanless Desktop Window s XBMC photo-1
US$ 1 - 128 MOQ: 1 Set
Key Specifications
Get Latest Price
Products Status:
Stock
Type:
Barebone System
Screen Size:
No Monitor
Contact Supplier Request Quote Chat Now
Shenzhen Eglobal Import & Export Co., Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Products Status Stock
Type Barebone System
Screen Size No Monitor
Processor Brand Intel
Memory Capacity Other, ≥ 4GB
Hard Drive Capacity Other, ≥ 1.5TB
Graphics Card Type Integrated Card
Brand Name Eglobal
Model Number V7-N2920
Place of Origin China

Baytrail  PC Mini Itx Computer  Intel Celeron Quad Core N2920 1.86Ghz Max 2.0Ghz All SoC Design HDMI VGA Display

Feature:
* Smallest Size: Nearly Cellphone 5S smart size
* Cheap Cost: Cost much lower than our Fanless Mini PC V2-C1037U with Intel Celeron 1037U
* Rather Light: Only 1KG Gross Weight
* Support OS: Windows 7/8 & Android, not support Windows XP & Linux
1. Special: 64 bits computing,  Energy-saving technology, Virtualization technology;
Support Wake-On-Lan; Support calls on function automatically;
Support SSD only, up to 256G SSD large volume;
Support Max 8GB DDR3L RAM, 1 RAM Slot;
I/O port: 1 VGA port, 1 HDMI port, 1 LAN port, 4 USB*2.0 Ports, 1 USB3.0 port
2. Stable: Intel SOC+Intel HD Graphics+Fanless
3. Smart: Fanless system, smart design cellphone 5S Size, no noise, be able to work 24 hours per day
4. Slim: Only 3cm body thickness, brushed black alloy case
5. Smooth: Support 3D games and HDMI full 1080P playback

6. Saving: Low consumption, TDP only 7.5W, save a lot much energy cost than normal computer every year
6. Strong: Work with any brand monitors; Suit for multiple application for example integrate with touch devices, industries, car repair shops, security, education, home as HTPC, business, fanancial and projects
Fanless Mini PC USB3.0 Main Features
1. Processor: Bay Trail M Onboard Intel Celeron N2920 1.86GHz Max 2.0GHz or N2930 1.83GHz Max 2.16GHz(ship out at random per in stock) Quad Core 4 Threads
2. Compitable Operating System:  Windows 7/ Windows 8/Android
3. Storage (optional): SSD: 8GB/16GB/32GB/64GB/128GB/256G
4. Memory (optional): 2GB/4GB/8GB N2920 DDR3L-1066 Or N2930 DDR3L-1333 1.35Voltage
5. Resolution: Support  2560*1600 P HD resolution
6. Network: 1000Mbps Adaptive Ethernet RJ45
Package details:
1. Include Mini PC, Power Adapter, 1* HDMI Cable, Vesa Bracket, Dual WiFi Antennas(if you choose uprading wifi)
2. Item Size: 140*100*30mm
3. Neutral Package size: 150*125*85mm



Fanless Mini PC V7-N2920

General

CPU

Onboard Intel Celeron N2920 1.86GHz Quad Core Four Thread Max 2GHz(Turbo boost Technology) processor

CPU(FSB)

100MHz

Lithography

22 nm

Max TDP

7.5W

L2 Cache

2MB

Instruction Set

64-bit

BOIS

AMI BIOS, ACPI supported

Chipset

Intel SOC

Memory

Memory Type

Memory Channels

1* SD-DDR3 SDRAM slot

DDR3L-1066, Max 8GB

2

Storage

SSD: 8G/16G/32G/64G/128G/256G

Cant install HDD

Operating System

Windows 7/Windows 8/ Android

Audio

ALC662 chip, 6 channel sound

Network

Onboard RTL8111DL10/100Mbps/1000Mbps BaseT LAN

Optional 300M WIFI with dual antenna or 300M WiFi&Bluetooth

Video

Intel HD Graphics

Graphics Base Frequency 313 MHz

Graphics Max Dynamic Frequency 844 MHz

Intel® Quick Sync Video

support VGA and HDMI full screen HD playback

I/O port

front panel ports

1* DC IN, 1* Power indicator and switch, 4*USB2.0 ports, 1*USB3.0 port

Backside ports

1*HDMI port, 1*VGA port, 1*LAN port(RJ-45), 1*MIC, 1*SPK

Internal ports

1*mini-PCIE port(m-SATA SSD, 3Gbps)

1*mini-PCIE port(WIFI)

Power and Working Environment

Input

DC100-240V AC/50-60Hz

Output

DC 12V~19V/3A

Operating Temperature

0/70 Centigrade(32F~140F)

Storage Temperature

-20/+80 Centigrade

Relative Humidity

10%~90% (non-condensing)

energy-saving

Support Energy-saving technology, Speedstep

64 bit computing

Support 64 bit computing

virtualization

Support Virtualization technology

hyper-threading

NO

Product Dimension & Details

Size

140*100*30MM

Weight

1.0kg

Consumption

7~15W

Shell

All black aluminum alloy

Package Content

Mini PC, Power Adapter
