Specifications
1.Densification of precast concrete2.Compaction of products in containers
3.Non-destructive testing
4.Low noise and durable
The above vibration isolation table is carbon steel , spray white paint ,different color
for your reference.
The moter of the vibration isolation table can increase ,and the vibration plane of the
vibration isolation table can be design as your need.
vibrating table is also called compacting platform. vibrating table
table is mainly used for contacting concrete . vibration table can decrease
and remove the gap or air between concrete material.
a. vibrating table structure: vibrating table mainly consists
ofbottom brackets, upper platform, vibrating motor and shock-absorbing device.
b. Three dimensional vibrating motion: a. horizontal b. vertical. c. un to down.
c. Spring: Steel spring, rubber spring, Composite spring.
d. Motor quantity should be even number, such as 2, 4, 6, 8…
1. Invibrating table working process, By adjusting the vibrating force, the
material can realize a ideal type.
2. The vibrating motor is vibrating source. Low noise and consumption, and be easy to
maintain.
3. Simple structure. Light weight, small volume, reliable working, and be easy to install.
4. Vibration model: up to down, screw vibration and dimensional vibration.
5. Large power and platform, Max power can arrive to 7.5kw. Max loading: 8 T.
6. Height can be adjustable. So it is suitable for product line.
7. Infinitely variable speeds.
8. Auto locking function. It can make sure the manufacturing security.
ZDP seriesvibrating table can be widly used in metallury,mould,food,Chemical
and Building material etc
vibrating table are designed to settle and compact dry bulk materials in various
types of containers. vibrating table application provides either a sizeable increa
se in the net weight of the container or reducing in the container size with subsequent savings in
shipping and storage space.
vibrating table are available in two types Electromagnetic & Electromechanical.
The choice of the proper type and model depends upon the application, characteristics of the
material or objects being handled, its reaction to vibration, the maximum weight to be handled
and the type of container.
Model |
Aera(square meter) |
powder(kw) |
Amplitude(mm) |
Weight(kg) |
ZDP-500×500 |
0.25 |
2×0.25 |
2-5 |
300 |
ZDP-1000×1000 |
1 |
2×0.4 |
2-5 |
600 |
ZDP-1200×1200 |
1.44 |
2×3 |
2-5 |
1200 |
ZDP-1500×1500 |
2.25 |
2×3 |
2-5 |
2000 |
ZDP-3000×3000 |
9 |
6×1.5 |
2-5 |
3000 |
