US$ 1 - 3
MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Shaanxi, China
Brand Name:
Smartdisplays
Model Number:
SC1602OLED
Payment & Shipping
Payment Methods:
Port of Shipment:
xi'an
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Shaanxi, China
Brand Name
Smartdisplays
Model Number
SC1602OLED
Specifications
Display Mode: Passive Matrix OLEDDisplay Color: Yellow(monochrome)
Drive Duty: 1/16 Duty
Controller Driver:US2066
1. Color: Yellow
2. Driver IC: US2066
3. Interface:4-/8-bit 68XX/80XX Parallel, SPI, I2C
4. Operating Voltage:3.3V
5. Drive Duty:1/16 duty
6. Operating temp:-40~70°C
7. storage temp:-40~85°C
Items | Specification | Unit |
Diagonal A/A Size | 2.26 | Inch |
Number of dots | 16 Characters ( 5×8 dots )×2 Lines | dot |
Module size | 80×36×4 | mm |
Active Area | 56.22×11.52 | mm |
viewing Area | 57×14.52 | mm |
Character Pitch | 3.55×5.95 | mm |
Character Size | 2.97×5.57 | mm |
Dot Pitch | 0.60×0.70 | mm |
Dot Size | 0.57×0.67 | mm |
General Tolerance | ±0.20 | mm |
