Home > Lights & Lighting > LED Lighting Decoration > LED Strip Light > Non Waterproof Ip67 WS2811 LED Light Strip 24 90LEDs RGB IC WS2811 12V 30LEDSs 48LEDs 60LEDs per Meter for Lighting Decoration

Non Waterproof Ip67 WS2811 LED Light Strip 24 90LEDs RGB IC WS2811 12V 30LEDSs 48LEDs 60LEDs per Meter for Lighting Decoration

Non Waterproof Ip67 WS2811 LED Light Strip 24 90LEDs RGB IC WS2811 12V 30LEDSs 48LEDs 60LEDs per Meter for Lighting Decoration thumbnail-1
Non Waterproof Ip67 WS2811 LED Light Strip 24 90LEDs RGB IC WS2811 12V 30LEDSs 48LEDs 60LEDs per Meter for Lighting Decoration photo-1
US$ 6.5 - 15 MOQ: 5 Meters
Key Specifications
Get Latest Price
LED Light Source:
5050 RGB
Type:
Flex LED Strips
Input Voltage(V):
12
Contact Supplier Request Quote Chat Now
Shenzhen Ranger LED Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source 5050 RGB
Type Flex LED Strips
Input Voltage(V) 12
Lamp Power 90
Working Temperature(℃) -20, 60
Working Lifetime(Hour) 50000
Lamp Body Material Copper
Certification CE
Emitting Color Changeable
Place of Origin Guangdong, China
Brand Name Ranger
Model Number RL-2811-5050RGB-90







Product Description







Chasing addressable dmx rgb led strip IC WS2811 12V 30LEDSs 48LEDs 60LEDs per meter for Lighting decoration



IC TYPE ITEM NO. WIDTH (mm) LED QTY IC QTY PIXEL QTY VOLT POWER
WS2811
TM1829
TM1804
UCS1903
INK1003
LX1003
GW6206 		RL-ICNO-5050RGB-10 10 10 10 10 5 3
RL-ICNO-5050RGB-24 10 24 24 24 5 7.5
RL-ICNO-5050RGB-30 10 30 10 10 12 9
RL-ICNO-5050RGB-48 10 48 16 16 12 14
RL-ICNO-5050RGB-60 10 60 20 20 12 18
RL-ICNO-5050RGB-90
 10 90 30 30 12 27
RL-ICNO-5050RGB-96 20 96 32 32 12 30
RL-ICNO-5050RGB-32 10 32 32 32 5 10
RL-ICNO-5050RGB-48 10 48 48 48 5 14.4
RL-ICNO-5050RGB-50 10 50 50 50 5 15



 Non Waterproof ip67 WS2811 LED Light Strip 24 90LEDs RGB IC WS2811 12V 30LEDSs 48LEDs 60LEDs per meter for Lighting decorationNon Waterproof ip67 WS2811 LED Light Strip 24 90LEDs RGB IC WS2811 12V 30LEDSs 48LEDs 60LEDs per meter for Lighting decorationNon Waterproof ip67 WS2811 LED Light Strip 24 90LEDs RGB IC WS2811 12V 30LEDSs 48LEDs 60LEDs per meter for Lighting decoration

Connection:

1) Signal wire: DC+,  DAT, GND
2) DC+ and GND connect to power supplier; DAT and GND connect to controller
3) Relative Controller: SPI controller support WS2801; when use DMX decorder, can connect to DMX system
4) Support online control



Color:
1) Each pixel can be controlled individually
2) Can show any color
3) Can be used as flexible led display screen to show image and video



Installation Notice:
1) Make sure the connection is correct according to the diagram
2) Pay attention to the parameters limit of voltage. DO NOT run over the peak value
3) Keep the surface of installation clean and smooth avoid breaking off
4) Avoiding the crook area just the position of LED and other components, in order to protect the product and extend the life span of the product



Advantage:
1.Environment friendly.
2.Long lifespan and Energy-saving.

3.Experienced employees that capable for good service

4.Considerate and kind sales-after service.

5.Strict QC procession, ensure each product is high quality.
