D/C IAC-A5D3X-Kit
Package each pc quad core ram a package
Model Number IAC-A5D3X-Kit
Type Other, Atmel
Brand Name QY
Place of Origin Zhejiang, China

Cortex-A5 Linux Board  A5D3X  quad core ram

 1.Atmel SAMA5D3 CPU, 536MHz ARM Cortex-A5 core ARM v7-A ISC
2.With floating point arithmetic unit,64-bit inside Bus architecture and 32-bit wide DDR controller,operation frequency up to 166MHz,high accuracy calculation and rapid processing data application;
3. Can choose different type of processor to get different function combination, optimize costs, and all models PIN compatibility;
4.Can expand 7-ch port, 2-ch CAN bus, 2-ch Ethernet interface;
5. Whole board runs with high-speed, and power consumption is lower than 1 w, with functions of low power consumption mode,which is ideal for battery-powered applications;
6.Abundant external interfaces, can replace Atmel ARM9 series products, and upgrade the product perfect;
7.Support linux 3.6 and android 4.0.



Industrial Cortex-A5 CPU!

Processor performance improve greatly;
Provide a complete design data;
4 types CPU for different applicaiton:
Optimize resources, maximum interface demand ;
...

Professional Hardware Design!

Pay attention to details,thoroughly defeat learning board;
Professional wiring, easy on testing;
The core board: 6- layer PCB design;
The back plane: 4- layer PCB design;

…

Abundant Interface Resource!

Stable,abundant interface project;
UART(A5D35 with own 7-ch );
CAN(A5D345with own 2-chc);
LCD & VGA interface;
Multiplexing IO reserved;

…

Excellent Industrial Connection Device!

Core board connect with back plane stably;
2 x 100 pin 0.8 space;
Excellent electric performance and environment performance;

…
A5D3X-ortex-A5 Linux Board  ,ATMEL SAMA5D3X series Chip,Cortex-A5 Core,it has standard SAMA5D34,in order to reduce the cost, the rest of the types are pin compatible, only for the batch user.:

  SAMA5D31 SAMA5D33 SAMA5D34 SAMA5D35
LCDC √ √ √
GMAC   √ √ √
EMAC √     √
CAN0,CAN1     √ √
HSMCI2 √   √ √
UART0 √     √
UART1 √     √
TC1       √

Development kit  Core Module is designed by 6-floor PCB; the volume is only card size; together with CPU, DDR2 RAM, NandFlash, DataFLash, network; using 5V dc power supply, low power consumption; 2*100 B to B connectors lead various commonly used interfaces; suitable for batch users.


A5D3X Development kit  is a general standard reference design board for A5 core board, with commonly used interfaces, such as TFT-LCD, touch screen, VGA, CAN bus, gigabit network interface, high-speed USB HOST, SD card, RS232485 serial port, audio, MIC, etc; support +6V~+23V wide range voltage power supply; can provide a complete design material for user to develop or custmize.



Cortex-A5 Linux Board Stamp Module quad core ram Specifications

Cortex-A5 Linux Board quad core ram Resource Introduction:

CPU Processor
• ATMEL SAMA5D3X,Cortex A5 core
• 536MHz
DDR RAM Memory
• 256MB DDR2 RAM,333MHz,32bit data bus
FLASH Storage
• On-board 2M DataFlash (DB45161D) A5D3X
• On-board 256M*8bits NandFlash (K9F2G08U0B)could change a large capacity or industrial chip according to customer's requirement
• 2*100 pin 0.8mm spacing B to B
Other Onboard Resource
• DM9162 net chip,support 10M/100M Ethernet with RGMII mode
• Power management, provide 1.8V, 3.3V,5.0V Voltage input
PCB Specification & Size
• Using 6-lay PCB high precision process, and has the best electrical properties and anti-jamming performance
• 74 x 53 x 1.5mm
Working temperature
• Working temperature: -20°C~ 70°C (batch user could customize -40°C~ 85°C)
• Humidity Range: 5%~ 95%, Non-Condensing
Low Power Consumption
• 5v Dc power supply, low power consumption, <1W
OS Support
• Linux 3.6.9 + QT4
• Android 4



solo development board cortex dual core development board cortex quad core development board cortex RAM solo development board cortex dual core development board cortex quad core development board cortex RAM

Cortex-A5 Linux Board  ( A5D3X ) quad core ram  Software & Technical Support

solo development board cortex dual core development board cortex quad core development board cortex RAM
NO. Item Function
J3 Audio output interface Audio output
J4 Route input interface Audio input
J5 MIC input interface MIC input
J6 TFT-LCD,Touch screen Expand color LCD screen, drive 4-wire resistive touch screen
J7 TFT-LCD Power 3.3V/5V  optional power supply jumper
J8 VGA interface VGA video output, and display connection
J9 Debug serial port Download, communication
J10 COM 1 232485
J11 COM 2 232485
J12 COM 3 RS232
J13 COM 4 RS232
J14 USB 2.0 Device High-speed USB(480MHz) for downloading program
J15 USB 2.0 Host USB Host
J16 SD card interface 1 SD card storage
J17 SD card interface 2 SD card storage
J18 Ethernet interface 10/100M Ethernet
J19 EBI bus interface CPU internal bus
J20 Monitor interface COMS interface,Video acquisition or used as a GPIO
J21 Matrix keyboard 8 x 8 keyboard interface, can used as GPIO
J22 SPI interface SPI bus interface
J23 Standard JTAG interface Simulation, Debugging
J24 Power interface 12V power input, support +6 ~+25V wide range power supply
J25 Power output 3.3V/5V output
K1 Reset button System reset
K2 Wake-up button Sleep state activation
S1 Power swith Control power supply

Cortex-A5 Linux Board Technical Support:

• The problems that customer encounter in the process of development on the products
• System cut, according to customer's requirements
• Develop related drivers, according to the demand of customer(another pay)
• Customized development of back plane, according to customer's requirements(another pay)

Cortex-A5 Linux Board (Cortex-A5) quad core ram  Order Infomation

Item IAC-A5D3X-Kit
Standard accessories (1)12V/2A power supply (2)1-wire cross serial line (3) CD of DVD development (4)4-wire RS232 serial line (5)mini USB wire (6) packing box
DVD resources Linux Compilers Cross-compiler arm-arago-linux-gnueabi
Tool software Supporting terminal, writing, download tools
Device manual Main component's datasheet of back plane
User manual About all development and use
Image file bootstarp,u-boot, kernel and file system
Test source code Test routines and source codes of all interfaces
System source code
 Including bootloader, kernel,  file system, QT source code and madplay
Schematic Back plane's schematic in PDF format
Packaging library Component packaging library of evaluation board
LCD options(another pay) 4.3' LCD module + 4-wire resistive touch screen + USB cable
5.6' LCD module + 4-wire resistive touch screen + USB cable
6.4' LCD+ 4-wire resistive touch screen + USB cable + inverter
7' LCD module + 4-wire resistive touch screen + USB cable
8' LCD module + 4-wire resistive touch screen + USB cable
10.4' LCD+ 4-wire resistive touch screen + USB cable + inverter
Module options(another pay) TTL to LVDS module
TTL to VGA module
Sales hotline 86-571-87858811,86-571-87858822

Cortex-A5 Linux Board ( A5D3X ) quad core ram  Application:

• Textile Industry, Numeric Control Industry, Automobile Electronics, Industrial Touch Screen Control System, Robot Vision, Media Deal Wireless Application, Digital Applicance, On-board Equipment, Communication Equipment, Network Terminal, etc.



Cortex-A5 Linux Board quad core ram  Our advantage:



 solo development board cortex dual core development board cortex quad core development board cortex RAM

Company Information

We are a high and new technology enterprise which is specializing in R&D, manufacture and sell embedded computer mainboard with high performance, low power consumption, low cost, small volume, and provides embedded hardware solutions. Over the years we focused on the development and services of embedded ARM industrial control products, which provides an easy-to-use development tools, reference design platform, product solutions of volume production for embedded development engineers. It helps customers to shorten the time from embedded board to products, and improves product quality. Our company is dedicated to become a leading embedded hardware and software supplier.

Our Services



Custom Service

Cooperation Mode Based on Core Module Customization The Whole Board Customization
Specification Customize expanded board based on our core module Offer complete mainboard customization based on the process platform we choose for you
Service Provide device selection, design suggestions, plate type design;
Principle diagram design, PCB design/modification, driver debug, driver source code, test source code, secondary development document writing, prototype;
Provide upper development, and the follow-up with long-term technical support, quality tracking service. 		Provide device selection, design suggestions, plate type design
Principle diagram design, PCB design/modification, driver debug, driver source code, test source code, secondary development document writing, prototype;
Provide upper development, and the follow-up with long-term technical support, quality tracking service.
Development Cycle

Provide mainboard test usually in 8-10 weeks(no fly line)

 Provide mainboard test usually in 2-3 months(no fly line)
Deliver Principle diagram, PCB, driver source code, prototype, etc. Principle diagram, PCB, driver source code, prototype, etc.
Service Extension(optional) Offer trial production/batch production, make production process, ensure the quality and delivery time;
EMC/MI Test;
Perfect quality assurance and after-sales service;
Product system, software and hardware upgrades. 		Offer trial production/batch production, make production process, ensure the quality and delivery time;
EMC/MI Test;
Perfect quality assurance and after-sales service;
Product system, software and hardware upgrades.
Expense Low, according to user's  requirements and difficulty level of R&D; The user who choose OEM could return part of R&D costs High, according to user's  requirements and difficulty level of R&D; The user who choose OEM could return part of R&D costs



Warranty

Hardware maintenance service

Hardware maintenance service means providing original factory maintenance,maintenance,repairing and recovering product performance for user’s mother board / core board .Including core board,baseboard,LCD,touch screen hardware fault test,electronic device replacement service.


Software and Hardware upgrading service

Software upgrading service means users installing operation system,installing equipment control software,according to customers’ requirement to customize winCE ,Linux OS . Hardware upgrading service means providing hardware upgrading scheme and hardware installing service.

Warranty Service

All parts product warranty period start form the purchase date, and under warranty is free of charge. The following circumstances products, not in warranty scope:
(1) Over the validation date of warranty;
(2) Belong to the user improper use or artificial damage;
(3) Without effective warranty certificate and invoice (can prove the goods in the warranty period excluded);
(4) Delivery product barcode or model not conform to physical commodity.
